| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 8520 × 2520 × 3100 mm | Load Capacity | 11 tons |
| Transport Package | Bare painting and waxing treatment | Transportation | Ro-Ro / Bulk ship / Container vessel |
| Production Capacity | 100 units/month | Tare Weight | Approx. 7645 kg |
| Origin | Hubei, China | Delivery Time | Within 30 days |
| ②Chassis Specification |
| Chassis Brand | Sinotruk | Model | ZZ1167G471CD1 |
| Drive Wheel | 4×2 | Wheelbase | 4700 mm |
| Driving Position | LHD or RHD | Cabin Seats | 3 |
| Cabin Color | According to customer requirements | Engine Model | MC05.18-40 |
| Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification | Engine Rated Power | 132 kW |
| Engine Horsepower | 180 HP | Engine Max Torque | 700 N·m / 1400-2400 r/min |
| Engine Number Of Cylinders | 4 | Engine Displacement | 4.58 L |
| Transmission Model | HW90510C2 | Pto | yes |
| Forward Gears | 10 | Reverse Gears | 2 |
| Transmission Type | Manual | Front Axle | 3.6t (Drum Brake) |
| Rear Axle | 8.0t (Drum Brake) | Axle Gear Ratio | 4.333 |
| Tire Specification | 9.00R20 16PR | Fuel Tank Capacity | 200 L |
| Fuel Tank Type | Aluminum alloy tank | Electric System | 24 V |
| Brake Type | Front and rear drum brakes | Braking Method | Air brake, air cut-off brake, ABS |
| ③Upper-Body Specification |
| Dumpster Volume | 7 cbm (stainless steel) | Cleaning System Main Components | Sweep disk support, sweep disk, oil cylinder, oil pipe, connecting rod, adjusting rod, hydraulic motor, etc. |
| Clear Water Tank Volume | 9 m³ (stainless steel) | Disk Motor Speed | 140 r/min |
| Cleaning Width | 2800–3200 mm | Number Of Sweep Disks | 2 pieces |
| Cleaning Operation Speed | 15–20 km/h | Brushes Per Sweep Disk | 22 pieces |
| Suction Ability | Density: 2.0 g/cm³; Cleaning operation time: 2–4 hours; Suction particle size: ≥100 mm | Sweep Disk Tilt Angle Adjustment | 5°–15° forward |
| Garbage Box Dump Angle | ≥45° | Water Spray Form | Low-pressure mist |
| Cleaning Efficiency | ≥96% | Main Components | Inlet high-pressure pump, water filter, pipeline, stainless steel nozzle, high-pressure nozzle, etc. |
| Operation Noise | | High Pressure Pump | German Pinfu |
| Auxiliary Engine | Model: B170, Brand: Cummins, Power: 170 HP | Installation Location | Dust collection: left and right front sweep plates; Dust suction and removal: inside the suction outlet of the suction cup |
