| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 5990 × 2100 × 2650 mm | Load Capacity | 4 / 5 tons |
| Transport Package | Bare painting and waxing treatment | Transportation | Ro-Ro / Bulk ship / Container vessel |
| Production Capacity | 100 units/month | Tare Weight | Approx. 4000 kg |
| Origin | Hubei, China | Delivery Time | Within 30 days |
| ②Chassis Specification |
| Chassis Brand | Sinotruk | Model | ZZ1047D3415D145 |
| Drive Wheel | 4×2 | Wheelbase | 3360 mm |
| Cabin Model | 2080 | Driving Position | LHD or RHD |
| Cabin Seats | 3 | Cabin Color | According to customer requirements |
| Engine Model | YN38CRD1 | Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification |
| Engine Rated Power | 95 kW | Engine Horsepower | 129 HP |
| Engine Max Torque | 365 N·m / 1600-2400 r/min | Engine Number Of Cylinders | 4 |
| Engine Displacement | 3.76 L | Transmission Model | WLY6TS55 |
| Pto | yes | Forward Gears | 6 |
| Reverse Gears | 1 | Transmission Type | Manual |
| Synchronized | Yes | Front Axle | 2.4T |
| Rear Axle | 4.2T | Axle Gear Ratio | 4.875 |
| Tire Specification | 7.00R16 14PR | Fuel Tank Capacity | 120 L |
| Fuel Tank Type | Aluminum alloy tank | Electric System | 24 V |
| Brake Type | Front and rear drum brakes | Braking Method | Air brake, air cut-off brake, ABS |
| ③Upper-Body Specification |
| Tank Thickness | Carbon steel shell 5 mm, ends 6 mm, inner PE layer 18 mm | Tank Shape | Oval or square (optional) |
| Garbage Compactor Truck Tank Materials | Q235 carbon steel (special steel) | Tank Design | Integral leak-proof design |
| Unloading Time | ≤45 s | Control Mode | Electric/Manual/Remote (three modes standard) |
| Engine Power Control | Fully automatic | Max Hydraulic System Pressure | 20 MPa |
| Manufacturing Process | Whole plate forming | Control System | PLC |
| Compaction Ratio | 1:3 to 1:4 | Control Panel Language | English or as requested |
| Garbage Compactor Truck Hopper Effective Volume | ≥0.8 m³ | Standard Accessories | Dustbin lifter, ladder, warning lights, emergency stop button, handrail, fire extinguisher, basic tool kit, English manual |
| Loading Method | Rear loading, optional bin lifting system | Optional | Rear view camera and backup alarm; Italian multi-way valve; 240L (single or double bin) or standard 660L/1100L bins with bin lifter |
