| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 8520 × 2550 × 3100 mm | Transport Package | Bare painting and waxing treatment |
| Transportation | Ro-Ro / Bulk ship / Container vessel | Production Capacity | 100 units/month |
| Tare Weight | Approx. 11000 kg | Origin | Hubei, China |
| Delivery Time | Within 30 days | | |
| ②Chassis Specification |
| Chassis Brand | Sinotruk | Model | ZZ1167G471CD1 |
| Drive Wheel | 4×2 | Wheelbase | 4700 mm |
| Driving Position | LHD or RHD | Cabin Seats | 3 |
| Cabin Color | According to customer requirements | Engine Model | MC05.18-40 |
| Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification | Engine Rated Power | 132 kW |
| Engine Horsepower | 180 HP | Engine Max Torque | 700 N·m / 1400-2400 r/min |
| Engine Number Of Cylinders | 4 | Engine Displacement | 4.58 L |
| Transmission Model | HW90510C2 | Pto | yes |
| Forward Gears | 10 | Reverse Gears | 2 |
| Transmission Type | Manual | Front Axle | 3.6t (Drum Brake) |
| Rear Axle | 8.0t (Drum Brake) | Axle Gear Ratio | 4.333 |
| Tire Specification | 9.00R20 16PR | Fuel Tank Capacity | 200 L |
| Fuel Tank Type | Aluminum alloy tank | Electric System | 24 V |
| Brake Type | Front and rear drum brakes | Braking Method | Air brake, air cut-off brake, ABS |
| ③Upper-Body Specification |
| Max Lifting Weight | 6300 kg | Wrecker Type | flatbed |
| Flatbed Body Lw | 5100×2550 mm | Flatbed Body Min Angle | 7.6° |
| Flatbed Body Max Loading Capacity | 12000 kg | Winch Rating Pulling Capacity | 10000 kg |
| Length Of Steel Wire Rope | 21 m | Others Equipment | Bilateral linkage operation, 4 straps, 1 tool box, L-shaped tire support frame, 1 pair of sleeves, 2 auxiliary small wheels |
| Max Lifting Weight Under All Extension | 600 kg | Effective Length Of Telescopic Boom | 2650 mm |
| Extend Retract Of Telescopic Boom | 1750 mm | Slope Angle Of Telescopic Boom | 7° |
| Folding Angle Under No Load | -7° to 92° | Folding Angle Under Load | -7° to 16° |
| Max Ground Distance | ≤900 mm | Landing Strength Per Leg | 80 kN × 2 |
| Hydraulic Hose | Tianhe, Guangdong Province | Hydraulic Joint | Germany technology and exported sealing rings |
| Hydraulic Lock | Jiangyin Mingcheng Hydraulic and Mechanical Co., Ltd. | Swivel Joint | Yangzhou Zhongmei Pressure Parts Co., Ltd. |
| Compartment Plate | One-step forming by Germany 3P2A 1000T punching machine | | |
