| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 5990 × 2100 × 2650 mm | Transport Package | Bare painting and waxing treatment |
| Transportation | Ro-Ro / Bulk ship / Container vessel | Production Capacity | 100 units/month |
| Tare Weight | Approx. 4500 kg | Origin | Hubei, China |
| Delivery Time | Within 30 days | | |
| ②Chassis Specification |
| Chassis Brand | Sinotruk | Model | ZZ1047D3415D145 |
| Drive Wheel | 4×2 | Wheelbase | 3360 mm |
| Cabin Model | 2080 | Driving Position | LHD or RHD |
| Cabin Seats | 3 | Cabin Color | According to customer requirements |
| Engine Model | YN38CRD1 | Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification |
| Engine Rated Power | 95 kW | Engine Horsepower | 129 HP |
| Engine Max Torque | 365 N·m / 1600-2400 r/min | Engine Number Of Cylinders | 4 |
| Engine Displacement | 3.76 L | Transmission Model | WLY6TS55 |
| Pto | yes | Forward Gears | 6 |
| Reverse Gears | 1 | Transmission Type | Manual |
| Synchronized | Yes | Front Axle | 2.4T |
| Rear Axle | 4.2T | Axle Gear Ratio | 4.875 |
| Tire Specification | 7.00R16 14PR | Fuel Tank Capacity | 120 L |
| Fuel Tank Type | Aluminum alloy tank | Electric System | 24 V |
| Brake Type | Front and rear drum brakes | Braking Method | Air brake, air cut-off brake, ABS |
| ③Upper-Body Specification |
| Maximum Operating Height | 33 m | Control System | Electro-hydraulic proportional control system and optional load proportional system can realize double action synchronization and speed regulation |
| Leveling System | Hydraulic automatic leveling | Rotation | 360° |
| Automatic Interlocking Device For Up And Down | For locking up and down the truck to prevent the risk of incorrect operation | Boom Type | Telescopic boom |
| Basket | 360-degree rotation | Outrigger Type | Front V Rear H type. Controlled independently |
| Horizontal Function | Real-time display | Outrigger Span | Vertical-4000mm/Horizontal-4350mm |
| Real Time Communication | There is a wireless intercom between the platform and the vehicle | Operation Mode | 4 operation modes; Electrical operation of the working platform; Ground remote control; Controller in the bucket |
| Emergency Lever | Emergency Electric Emergency Pump. When the engine and main pump fail, the emergency electric pump can be operated to ensure the operator can be sent to the ground. | | |
