| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 9800 × 2520 × 3335 mm | Transport Package | Bare painting and waxing treatment |
| Transportation | Ro-Ro / Bulk ship / Container vessel | Production Capacity | 100 units/month |
| Tare Weight | Approx. 18495 kg | Origin | Hubei, China |
| Delivery Time | Within 30 days | | |
| ②Chassis Specification |
| Chassis Brand | Sinotruk | Model | ZZ3257N3847B1 |
| Drive Wheel | 6×4 | Wheelbase | 3825+1350 mm |
| Driving Position | LHD or RHD | Cabin Seats | 3 |
| Cabin Color | According to customer requirements | Engine Model | WD615.47 |
| Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification | Engine Rated Power | 272 kW |
| Engine Horsepower | 371 HP | Engine Max Torque | 1500 N·m / 1100-1600 rpm |
| Engine Number Of Cylinders | 6 | Engine Displacement | 9.726 L |
| Transmission Model | HW19710 | Pto | HW50 Direct-coupled |
| Forward Gears | 10 | Reverse Gears | 2 |
| Transmission Type | Manual / Automatic | Synchronized | Yes |
| Front Axle | VGD95 (9.5T, Drum Brake) | Rear Axle | MCX16ZG Double Rear Axle (16T×2, Drum Brake) |
| Axle Gear Ratio | 5.451 | Tire Specification | 315/80R22.5 18PR |
| Front Suspension | 10-leaf spring | Rear Suspension | 12-leaf spring |
| Fuel Tank Capacity | 300 L | Fuel Tank Type | Aluminum alloy tank |
| Electric System | 24 V | Brake Type | Front and rear drum brakes |
| Braking Method | Air brake, air cut-off brake, ABS | | |
| ③Upper-Body Specification |
| Wrecker Type | integrated | Integrated Wrecker Body Type | 25T integrated tow truck body |
| Integrated Wrecker Main Boom Type | Two-section hexagonal boom | Integrated Wrecker Tow Boom Type | Three-section tow boom |
| Integrated Wrecker Underlift Structure | Reinforced | Integrated Wrecker Vertical Boom Structure | Reinforced |
| Integrated Wrecker Cabin Type | Split-type cabin | Integrated Wrecker Operation | Dual-side linked control |
| Integrated Wrecker Wheel Lift Device | Equipped | Integrated Wrecker Warning Lights | Equipped |
| Integrated Wrecker Auxiliary Braking | 1 set of air pipe assembly | Integrated Wrecker Remote Control | Triple wireless remote control |
| Integrated Wrecker Valves | Imported Italian HYDAC valves | Integrated Wrecker Hydraulic Pump | Wanii dual-pump |
| Integrated Wrecker Structural Reinforcement | Reinforced stress-bearing parts | Integrated Wrecker Cabin Surface Treatment | Electrophoresis |
| Integrated Wrecker Accessories | 4 pairs of Y-type forks + 1 movable fork | Integrated Wrecker Lashing Chains | 2 pieces |
| Integrated Wrecker Underlift Fork Seats | 2 sets | | |
