| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 10500 × 2550 × 3500 mm | Transport Package | Bare painting and waxing treatment |
| Transportation | Ro-Ro / Bulk ship / Container vessel | Production Capacity | 100 units/month |
| Tare Weight | Approx. 18700 kg | Origin | Hubei, China |
| Delivery Time | Within 30 days | | |
| ②Chassis Specification |
| Chassis Brand | Sinotruk | Model | ZZ3317N3567B1 |
| Drive Wheel | 8×4 | Wheelbase | 1800+3500+1350 mm |
| Driving Position | LHD or RHD | Cabin Seats | 3 |
| Cabin Color | According to customer requirements | Engine Model | WD615.47 |
| Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification | Engine Rated Power | 272 kW |
| Engine Horsepower | 371 HP | Engine Max Torque | 1500 N·m / 1100-1600 rpm |
| Engine Number Of Cylinders | 6 | Engine Displacement | 9.726 L |
| Transmission Model | HW19710 | Pto | HW50 Direct-coupled |
| Forward Gears | 10 | Reverse Gears | 2 |
| Transmission Type | Manual | Synchronized | Yes |
| Front Axle | VGD95 (9.5T, Drum Brake) | Rear Axle | MCP16ZG (16T × 2, Double Reduction, Drum Brake) |
| Axle Gear Ratio | 5.26 | Tire Specification | 12.00R20 18PR Mixed Pattern |
| Fuel Tank Capacity | 300 L | Fuel Tank Type | Aluminum alloy tank / Steel fuel tank |
| Electric System | 24 V | Brake Type | Front and rear drum brakes |
| Braking Method | Air brake, air cut-off brake, ABS | Other Configurations | Intercooler Guard, Primary Parker Fuel Filter, Rear Tow Hook, Reverse Alarm, Exhaust Valve Brake (EVB) & 71°C Thermostat, Fire Extinguisher, External Engine Start/Stop Switch, Reinforced Front & Rear Wheels, Three Straps for Air Tank Mounting, Anti-theft Battery Box, Anti-theft Split-type Fuel Tank. |
| ③Upper-Body Specification |
| Wrecker Type | separated | Tow Truck Separated Max Lifting Weight | 40000 kg |
| Tow Truck Separated Max Lifting Weight Under All Extension | 25000 kg | Tow Truck Separated Effective Length Of Telescopic Boom | 3650 mm |
| Tow Truck Separated Extend Retract Of Telescopic Boom | 1750 mm | Tow Truck Separated Slope Angle Of Telescopic Boom | 7° |
| Tow Truck Separated Folding Angle Under No Load | -7° to 92° | Tow Truck Separated Folding Angle Under Load | -7° to 16° |
| Tow Truck Separated Max Ground Distance | 900 mm | Tow Truck Separated Landing Strength Per Leg | 80 kN × 2 |
| Tow Truck Separated Hydraulic Hose | Tianhe, Guangdong Province | Tow Truck Separated Hydraulic Joint | Germany technology and exported sealing rings |
| Tow Truck Separated Hydraulic Lock | Jiangyin Mingcheng Hydraulic and Mechanical Co., Ltd. | Tow Truck Separated Swivel Joint | Yangzhou Zhongmei Pressure Parts Co., Ltd. |
| Tow Truck Separated Compartment Plate | One-step forming by Germany 3P2A 1000T punching machine | | |
