| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 8520 × 2550 × 3100 mm | Load Capacity | 10-15t |
| Transport Package | Bare painting and waxing treatment | Transportation | Ro-Ro / Bulk ship / Container vessel |
| Production Capacity | 100 units/month | Tare Weight | Approx. 11000 kg |
| Origin | Hubei, China | Delivery Time | Within 30 days |
| ②Chassis Specification |
| Chassis Brand | Sinotruk | Model | ZZ1167G471CD1 |
| Drive Wheel | 4×2 | Wheelbase | 4700 mm |
| Driving Position | LHD or RHD | Cabin Seats | 3 |
| Cabin Color | According to customer requirements | Engine Model | MC05.18-40 |
| Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification | Engine Rated Power | 132 kW |
| Engine Horsepower | 180 HP | Engine Max Torque | 700 N·m / 1400-2400 r/min |
| Engine Number Of Cylinders | 4 | Engine Displacement | 4.58 L |
| Transmission Model | HW90510C2 | Pto | yes |
| Forward Gears | 10 | Reverse Gears | 2 |
| Transmission Type | Manual | Front Axle | 3.6t (Drum Brake) |
| Rear Axle | 8.0t (Drum Brake) | Axle Gear Ratio | 4.333 |
| Tire Specification | 9.00R20 16PR | Fuel Tank Capacity | 200 L |
| Fuel Tank Type | Aluminum alloy tank | Electric System | 24 V |
| Brake Type | Front and rear drum brakes | Braking Method | Air brake, air cut-off brake, ABS |
| ③Upper-Body Specification |
| Balancing System | Hydraulic support leg, straight extension structure, weight capacity is 6 tons per leg | Compartment Frame | Using thick seamless square tube, frame size: 7060×2450×2275mm |
| Thermal Insulation Layer | Polyurethane foam, average thickness ≥4 cm | Compartment Door | Aluminum door body with laminated composite inner panel |
| Lower Enclosure Door | Steel sheet | Ladder | Stainless steel folding extension ladder at rear door |
| Push Out Window | Openable glass window | Hot Water Boiler | Diesel fuel hot water boiler, thermal power 0.08 MW |
| Makeup Water Tank | Stainless steel | Heat Exchanger | Plate type heat exchanger |
| Softener | Stainless steel, vertical | Water Filter | Stainless steel, vertical |
| Shower Piping | Stainless steel piping combined with high temperature resistant PPR piping | Shower Nozzle | Stainless steel nozzle |
| Shower Switch | Stainless steel single-hole switch | Fan Heater | 2900W multi-functional electric heater |
| Mirror | Stainless steel mirror | Clothes Shoes Cabinet | Stainless steel, with 8 independent Transport Medium spaces |
| Double Sofa Stool | Seat cushion with leather surface | Accessories | Non-slip mats, coat hooks, waterproof curtains, etc |
| Mains Supply System | Special aviation connector, protection class IP67 | Generator | 5 kW petrol generator, electric start |
| Distribution Box | Stainless steel distribution box with air switch, ammeter, outlet, etc | Oil Tank | Vertical tank, 80 L |
| Oil Supply Equipment | Filter, oil pipe | Water Supply Pipeline | Stainless steel materials, 10 m hose with special connector |
| Water Tank | Stainless steel water tank with vent hole, drain valve, etc | Thermostatic Water Mixing Valve | Output water temperature adjustment range: 34–45 °C; constant temperature error: |
| Water Pump Self Priming | Maximum flow: 75 L/h | Drainage Pipe | 5 m hose with special connector |
| Long Row Alarm Light | 1.9 m red and blue long-row police light | Strobe Light | LED light, color lampshades, 4 pcs on each side |
| Alarm Master Control | With tweeter, controller, etc | Internal Floodlight | Waterproof, explosion-proof |
| External Floodlight | High-power LED vehicle lights: 2 pcs on left, 2 on right, 2 on rear | Reversing Monitoring System | 7-inch color display screen, waterproof camera |
