| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 5990 × 2100 × 2650 mm | Load Capacity | 5 tons |
| Transport Package | Bare painting and waxing treatment | Transportation | Ro-Ro / Bulk ship / Container vessel |
| Production Capacity | 100 units/month | Tare Weight | Approx. 4000 kg |
| Origin | Hubei, China | Delivery Time | Within 30 days |
| ②Chassis Specification |
| Chassis Brand | Sinotruk | Model | ZZ1047D3415D145 |
| Drive Wheel | 4×2 | Wheelbase | 3360 mm |
| Cabin Model | 2080 | Driving Position | LHD or RHD |
| Cabin Seats | 3 | Cabin Color | According to customer requirements |
| Engine Model | YN38CRD1 | Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification |
| Engine Rated Power | 95 kW | Engine Horsepower | 129 HP |
| Engine Max Torque | 365 N·m / 1600-2400 r/min | Engine Number Of Cylinders | 4 |
| Engine Displacement | 3.76 L | Transmission Model | WLY6TS55 |
| Pto | yes | Forward Gears | 6 |
| Reverse Gears | 1 | Transmission Type | Manual |
| Synchronized | Yes | Front Axle | 2.4T |
| Rear Axle | 4.2T | Axle Gear Ratio | 4.875 |
| Tire Specification | 7.00R16 14PR | Fuel Tank Capacity | 120 L |
| Fuel Tank Type | Aluminum alloy tank | Electric System | 24 V |
| Brake Type | Front and rear drum brakes | Braking Method | Air brake, air cut-off brake, ABS |
| ③Upper-Body Specification |
| Box Material | Stainless steel interior, outer fiberglass; base plate: stainless steel full weld | Cargo Box Interior Dimensions Lwh | 4160×22040×1950 mm |
| Box Plate Thickness | Sides 60 mm, bottom 90 mm | Door Trim Frame | 201/304 stainless steel |
| Insulation Material | XPS composite insulation board | Processing Technology | Negative pressure integral bonding process |
| Product Category | Jinglong Third Generation | Core Advantages | Thermal break insulation + built-in temperature monitoring (unique in the industry) |
| Special Configurations | Stainless steel box, sewage tank, disinfectant tank, special refrigeration unit for medical waste, fire extinguisher, ultraviolet disinfection lamp, front exhaust, sprinkler system, side door, internal partition door | Optional Negative Pressure System | Filter, negative pressure control, ozone sterilization and disinfection device |
