| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 8520 × 2550 × 3100 mm | Load Capacity | 10-15t |
| Transport Package | Bare painting and waxing treatment | Transportation | Ro-Ro / Bulk ship / Container vessel |
| Production Capacity | 100 units/month | Tare Weight | Approx. 11000 kg |
| Origin | Hubei, China | Delivery Time | Within 30 days |
| ②Chassis Specification |
| Chassis Brand | Sinotruk | Model | ZZ1167G471CD1 |
| Drive Wheel | 4×2 | Wheelbase | 4700 mm |
| Driving Position | LHD or RHD | Cabin Seats | 3 |
| Cabin Color | According to customer requirements | Engine Model | MC05.18-40 |
| Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification | Engine Rated Power | 132 kW |
| Engine Horsepower | 180 HP | Engine Max Torque | 700 N·m / 1400-2400 r/min |
| Engine Number Of Cylinders | 4 | Engine Displacement | 4.58 L |
| Transmission Model | HW90510C2 | Pto | yes |
| Forward Gears | 10 | Reverse Gears | 2 |
| Transmission Type | Manual | Front Axle | 3.6t (Drum Brake) |
| Rear Axle | 8.0t (Drum Brake) | Axle Gear Ratio | 4.333 |
| Tire Specification | 9.00R20 16PR | Fuel Tank Capacity | 200 L |
| Fuel Tank Type | Aluminum alloy tank | Electric System | 24 V |
| Brake Type | Front and rear drum brakes | Braking Method | Air brake, air cut-off brake, ABS |
| ③Upper-Body Specification |
| Dc Battery Voltage Range | 500V~850Vdc-500V | Dc Max Input Current | 550A or 1100A |
| Dc Rated Output Power | 250kW or 500kW | Output Wire Connection | 3W+N+PE |
| Output Rated Voltage | 400Vac | Rated Output Current | 361A or 722A |
| Output Isolation Method | Transformer | Grid Connected Voltage Range | 400Vac(-20%~+10%) |
| Grid Connected Frequency Range | 50±5Hz/60±5Hz | Grid Connected Overload Capacity | 110% for 10 minutes, 120% for 1 minute |
| Grid Connected Thdi | ≤3% | Grid Connected Power Factor | -0.99(lagging)~ +0.99(leading) |
| Rated Voltage | 400V | Grid Voltage Range | 400VAC±10% |
| Grid Frequency Range | 50Hz/60Hz | Off Grid Integrated With Unbalanced Load Capacity | ≤100% |
| Off Grid Thdi | ≤3%(Pure resistive load) | Off Grid Overload Capacity | 110% for 10 minutes, 120% for 1 minute |
| Working Environment Temperature | -15°C~50°C | Max Working Temperature Range | -20°C~55°C |
| Ideal Working Temperature Range | 20°C~30°C | Altitude | ≤4000m (over 2000m the capacity will be degraded) |
