| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 12000 × 2525 × 3500 mm | Load Capacity | 28 / 32 tons |
| Transport Package | Bare painting and waxing treatment | Transportation | Ro-Ro / Bulk ship / Container vessel |
| Production Capacity | 100 units/month | Tare Weight | Approx. 11700 kg |
| Origin | Hubei, China | Delivery Time | Within 30 days |
| ②Chassis Specification |
| Chassis Brand | Sinotruk | Model | ZZ3317N3567B1 |
| Drive Wheel | 8×4 | Wheelbase | 1800+3500+1350 mm |
| Driving Position | LHD or RHD | Cabin Seats | 3 |
| Cabin Color | According to customer requirements | Engine Model | WD615.47 |
| Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification | Engine Rated Power | 272 kW |
| Engine Horsepower | 371 HP | Engine Max Torque | 1500 N·m / 1100-1600 rpm |
| Engine Number Of Cylinders | 6 | Engine Displacement | 9.726 L |
| Transmission Model | HW19710 | Pto | HW50 Direct-coupled |
| Forward Gears | 10 | Reverse Gears | 2 |
| Transmission Type | Manual | Synchronized | Yes |
| Front Axle | VGD95 (9.5T, Drum Brake) | Rear Axle | MCP16ZG (16T × 2, Double Reduction, Drum Brake) |
| Axle Gear Ratio | 5.26 | Tire Specification | 12.00R20 18PR Mixed Pattern |
| Fuel Tank Capacity | 300 L | Fuel Tank Type | Aluminum alloy tank / Steel fuel tank |
| Electric System | 24 V | Brake Type | Front and rear drum brakes |
| Braking Method | Air brake, air cut-off brake, ABS | Other Configurations | Intercooler Guard, Primary Parker Fuel Filter, Rear Tow Hook, Reverse Alarm, Exhaust Valve Brake (EVB) & 71°C Thermostat, Fire Extinguisher, External Engine Start/Stop Switch, Reinforced Front & Rear Wheels, Three Straps for Air Tank Mounting, Anti-theft Battery Box, Anti-theft Split-type Fuel Tank. |
| ③Upper-Body Specification |
| Asphalt Tank Capacity | 8 cbm | Asphalt Tank Material | Stainless steel scrub, with insulating layer |
| Asphalt Tank Layer Thickness | 80 mm | Asphalt Tank Spray Medium | Hot asphalt, emulsified asphalt and residual oil |
| Gravel Tank Capacity | 12 cbm | Gravel Tank Material | Carbon steel |
| Gravel Tank Shape | Trapezoidal bucket | Bitumen Pump Model | QGB950 |
| Bitumen Pump Displacement | 950 L/min | Hydraulic Pump | Chinese local GPC4-50-20-16 |
| Proportioner Valve Model | EFBG-03-160-HF (Taiwan) | Hydraulic Drive Motor | 05-130-BD31 (Chinese local) |
| Spraying Material | Hot asphalt, hot modified asphalt, cutback asphalt, emulsified asphalt, rubber modified asphalt | Spraying Width | 4.5 m (6 m optional) |
| Spraying Capacity | 0.25–3.5 L/min | Number Of Intelligent Spray Nozzles | 32 |
| Stone Out Door | 36 | Burner Model | Double burner, G20 (Made in Italy), 200,000 kcal/h |
| Thermal Oil Pump Model | 40-25-160 (Made in China) | Gasoline Engine Power | 5.5 kW (Made in China) |
| Rear Monitor Spec | 7 inches, full color | Control Mode | Computer control, one control one, intelligent, in cabinet |
| Heating Up Mode | Self-Heating by Thermal Oil | Stones Standard | S3–S24 mm |
