| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 12000 × 2525 × 3500 mm | Load Capacity | 28 / 32 tons |
| Transport Package | Bare painting and waxing treatment | Transportation | Ro-Ro / Bulk ship / Container vessel |
| Production Capacity | 100 units/month | Tare Weight | Approx. 11700 kg |
| Origin | Hubei, China | Delivery Time | Within 30 days |
| ②Chassis Specification |
| Chassis Brand | Sinotruk | Model | ZZ3317N3567B1 |
| Drive Wheel | 8×4 | Wheelbase | 1800+3500+1350 mm |
| Driving Position | LHD or RHD | Cabin Seats | 3 |
| Cabin Color | According to customer requirements | Engine Model | WD615.47 |
| Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification | Engine Rated Power | 272 kW |
| Engine Horsepower | 371 HP | Engine Max Torque | 1500 N·m / 1100-1600 rpm |
| Engine Number Of Cylinders | 6 | Engine Displacement | 9.726 L |
| Transmission Model | HW19710 | Pto | HW50 Direct-coupled |
| Forward Gears | 10 | Reverse Gears | 2 |
| Transmission Type | Manual | Synchronized | Yes |
| Front Axle | VGD95 (9.5T, Drum Brake) | Rear Axle | MCP16ZG (16T × 2, Double Reduction, Drum Brake) |
| Axle Gear Ratio | 5.26 | Tire Specification | 12.00R20 18PR Mixed Pattern |
| Fuel Tank Capacity | 300 L | Fuel Tank Type | Aluminum alloy tank / Steel fuel tank |
| Electric System | 24 V | Brake Type | Front and rear drum brakes |
| Braking Method | Air brake, air cut-off brake, ABS | Other Configurations | Intercooler Guard, Primary Parker Fuel Filter, Rear Tow Hook, Reverse Alarm, Exhaust Valve Brake (EVB) & 71°C Thermostat, Fire Extinguisher, External Engine Start/Stop Switch, Reinforced Front & Rear Wheels, Three Straps for Air Tank Mounting, Anti-theft Battery Box, Anti-theft Split-type Fuel Tank. |
| ③Upper-Body Specification |
| Control Mode | Electric/Manual/Remote (three modes standard) | Max Hydraulic System Pressure | 20 MPa |
| Control System | PLC | Control Panel Language | English or as requested |
| Standard Accessories | Dustbin lifter, ladder, warning lights, emergency stop button, handrail, fire extinguisher, basic tool kit, English manual | | |
