| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 9800 × 2520 × 3335 mm | Load Capacity | 21 / 25 tons |
| Transport Package | Bare painting and waxing treatment | Transportation | Ro-Ro / Bulk ship / Container vessel |
| Production Capacity | 100 units/month | Tare Weight | Approx. 11495 kg |
| Origin | Hubei, China | Delivery Time | Within 30 days |
| ②Chassis Specification |
| Chassis Brand | Sinotruk | Model | ZZ3257N3847B1 |
| Drive Wheel | 6×4 | Wheelbase | 3825+1350 mm |
| Driving Position | LHD or RHD | Cabin Seats | 3 |
| Cabin Color | According to customer requirements | Engine Model | WD615.47 |
| Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification | Engine Rated Power | 272 kW |
| Engine Horsepower | 371 HP | Engine Max Torque | 1500 N·m / 1100-1600 rpm |
| Engine Number Of Cylinders | 6 | Engine Displacement | 9.726 L |
| Transmission Model | HW19710 | Pto | HW50 Direct-coupled |
| Forward Gears | 10 | Reverse Gears | 2 |
| Transmission Type | Manual / Automatic | Synchronized | Yes |
| Front Axle | VGD95 (9.5T, Drum Brake) | Rear Axle | MCX16ZG Double Rear Axle (16T×2, Drum Brake) |
| Axle Gear Ratio | 5.451 | Tire Specification | 315/80R22.5 18PR |
| Front Suspension | 10-leaf spring | Rear Suspension | 12-leaf spring |
| Fuel Tank Capacity | 300 L | Fuel Tank Type | Aluminum alloy tank |
| Electric System | 24 V | Brake Type | Front and rear drum brakes |
| Braking Method | Air brake, air cut-off brake, ABS | | |
| ③Upper-Body Specification |
| Snow Melting Agent Distributor Tank Capacity | 8cbm | Spreading Width | Adjustable from 0 to 20 metres |
| Spreading Application Rate | 20–150 g/m² | Snow Removal Truck Snow Removal Shovel Dimensions | 2500 × 1200 × 900 mm |
| Snow Removal Truck Snow Removal Shovel Weight | 360 kg | Snow Removal Truck Snow Removal Shovel Effective Working Width | 2000–2500 mm |
| Snow Removal Truck Snow Removal Shovel Left Right Rotation Angle | ≥±30° | Snow Removal Truck Snow Removal Shovel Maximum Ground Clearance | 300–400 mm |
| Snow Removal Truck Snow Removal Shovel Obstacle Avoidance Height | 130 mm | Snow Removal Truck Snow Removal Shovel Snow Removal Thickness | ≤200 mm |
| Snow Removal Truck Snow Removal Shovel Snow Removal Efficiency | ≥90% | Snow Removal Truck Snow Removal Shovel Working Speed | 15–30 km/h |
| Snow Removal Truck Snow Roller Sweeper Dimensions | 2500 × 1100 × 900 mm | Snow Removal Truck Snow Roller Sweeper Diameter | 620 mm (standard) / 800 mm (optional) |
| Snow Removal Truck Snow Roller Sweeper Effective Working Width | > 2300 mm | Snow Removal Truck Snow Removal Thickness | ≤120 mm |
| Snow Removal Truck Snow Roller Sweeper Ascent Height | 200–400 mm | Snow Removal Truck Snow Roller Sweeper Hydraulic Flow Rate | 140–180 L/min |
| Snow Removal Truck Working Rotation Speed | ≥200–300 r/min | Snow Removal Truck Snow Roller Sweeper Removal Efficiency | 0.98 |
| Snow Removal Truck Snow Roller Sweeper Throwing Distance | 2–3 m | Snow Removal Truck Snow Roller Sweeper Working Speed | 5–40 km/h |
