| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 5990 × 2100 × 2650 mm | Transport Package | Bare painting and waxing treatment |
| Transportation | Ro-Ro / Bulk ship / Container vessel | Production Capacity | 100 units/month |
| Tare Weight | Approx. 4500 kg | Origin | Hubei, China |
| Delivery Time | Within 30 days | | |
| ②Chassis Specification |
| Chassis Brand | Sinotruk | Model | ZZ1047D3415D145 |
| Drive Wheel | 4×2 | Wheelbase | 3360 mm |
| Cabin Model | 2080 | Driving Position | LHD or RHD |
| Cabin Seats | 3 | Cabin Color | According to customer requirements |
| Engine Model | YN38CRD1 | Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification |
| Engine Rated Power | 95 kW | Engine Horsepower | 129 HP |
| Engine Max Torque | 365 N·m / 1600-2400 r/min | Engine Number Of Cylinders | 4 |
| Engine Displacement | 3.76 L | Transmission Model | WLY6TS55 |
| Pto | yes | Forward Gears | 6 |
| Reverse Gears | 1 | Transmission Type | Manual |
| Synchronized | Yes | Front Axle | 2.4T |
| Rear Axle | 4.2T | Axle Gear Ratio | 4.875 |
| Tire Specification | 7.00R16 14PR | Fuel Tank Capacity | 120 L |
| Fuel Tank Type | Aluminum alloy tank | Electric System | 24 V |
| Brake Type | Front and rear drum brakes | Braking Method | Air brake, air cut-off brake, ABS |
| ③Upper-Body Specification |
| Arm Max Working Height | 36m | Arm Type | Hexagonal 7-section telescopic arm |
| Arm Max Rear Working Range | 23m | Arm Max Side Working Range | 18m |
| Arm Raising Angle | 0–75° | Landing Leg Front Type | V-type |
| Landing Leg Rear Type | V-type | Leg Span Horizontal Vertical | 5400/4560 mm |
| Working Basket Type | Normal (Optional insulated type) | Working Basket Size | 1600×680×1000 mm |
| Working Basket Material | Stainless steel | Working Basket Loading Capacity | 200 kg |
| Operating System | CAN wireless remote control / manual operation | Turning Device | 180 degree (left and right each 90 degree) |
