| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 9800 × 2520 × 3335 mm | Load Capacity | 21 / 25 tons |
| Transport Package | Bare painting and waxing treatment | Transportation | Ro-Ro / Bulk ship / Container vessel |
| Production Capacity | 100 units/month | Tare Weight | Approx. 11495 kg |
| Origin | Hubei, China | Delivery Time | Within 30 days |
| ②Chassis Specification |
| Chassis Brand | Sinotruk | Model | ZZ3257N3847B1 |
| Drive Wheel | 6×4 | Wheelbase | 3825+1350 mm |
| Driving Position | LHD or RHD | Cabin Seats | 3 |
| Cabin Color | According to customer requirements | Engine Model | WD615.47 |
| Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification | Engine Rated Power | 272 kW |
| Engine Horsepower | 371 HP | Engine Max Torque | 1500 N·m / 1100-1600 rpm |
| Engine Number Of Cylinders | 6 | Engine Displacement | 9.726 L |
| Transmission Model | HW19710 | Pto | HW50 Direct-coupled |
| Forward Gears | 10 | Reverse Gears | 2 |
| Transmission Type | Manual / Automatic | Synchronized | Yes |
| Front Axle | VGD95 (9.5T, Drum Brake) | Rear Axle | MCX16ZG Double Rear Axle (16T×2, Drum Brake) |
| Axle Gear Ratio | 5.451 | Tire Specification | 315/80R22.5 18PR |
| Front Suspension | 10-leaf spring | Rear Suspension | 12-leaf spring |
| Fuel Tank Capacity | 300 L | Fuel Tank Type | Aluminum alloy tank |
| Electric System | 24 V | Brake Type | Front and rear drum brakes |
| Braking Method | Air brake, air cut-off brake, ABS | | |
| ③Upper-Body Specification |
| Tank Volume | 5000 L | Dust Suppression Vehicle Tank Materials | Carbon steel or aluminum alloy or stainless steel |
| Tank Inside Treatment | Anti-corrosion and anti-rust | Tank Shape | Oval or square (optional) |
| Front Spray Width | 16–20 m | Side Spray Width | 10–15 m |
| Rear Spray Width | 4–8 m | Water Pump (Self-priming) | QZ60/90, Yifeng or other Chinese brands, Flow 60 m³/h, Head 90 m |
| Dust Suppression Vehicle Other Equipment | Front direct spray / Rear sprinkling / Side watering / One hydrant connection | Manhole | DN450 (18 inches) |
| Liquid Line | DN50 (2 inches) | Filling Hose | 15 m |
| Top Safety Rail | 1 set | Dust Suppression Vehicle Mist Cannon Range | 80 m |
| Dust Suppression Vehicle Mist Cannon Horizontal Range | 100–120 m | Dust Suppression Vehicle Mist Cannon Fan Motor Power | 37 kW |
| Dust Suppression Vehicle Mist Cannon Operating Power | 11 kW | Dust Suppression Vehicle Mist Cannon Centrifugal Pump | Stainless steel multistage centrifugal pump |
| Dust Suppression Vehicle Mist Cannon Water Pump Flow | 170 L/min | Dust Suppression Vehicle Mist Cannon Vertical Spray Angle | -10° to +55° |
| Dust Suppression Vehicle Mist Cannon Horizontal Spray Angle | 0° to 360° | Dust Suppression Vehicle Mist Cannon Number Of Nozzles | 80 |
| Dust Suppression Vehicle Mist Cannon Atomization Fineness | 10–150 μm | Dust Suppression Vehicle Mist Cannon Filtration Accuracy | 250/60 μm/mesh |
| Dust Suppression Vehicle Mist Cannon Remote Control Distance | 100 m | Dust Suppression Vehicle Mist Cannon Generator Set Power | 120 kW |
