| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 8520 × 2520 × 3100 mm | Load Capacity | 11 tons |
| Transport Package | Bare painting and waxing treatment | Transportation | Ro-Ro / Bulk ship / Container vessel |
| Production Capacity | 100 units/month | Tare Weight | Approx. 7645 kg |
| Origin | Hubei, China | Delivery Time | Within 30 days |
| ②Chassis Specification |
| Chassis Brand | Sinotruk | Model | ZZ1167G471CD1 |
| Drive Wheel | 4×2 | Wheelbase | 4700 mm |
| Driving Position | LHD or RHD | Cabin Seats | 3 |
| Cabin Color | According to customer requirements | Engine Model | MC05.18-40 |
| Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification | Engine Rated Power | 132 kW |
| Engine Horsepower | 180 HP | Engine Max Torque | 700 N·m / 1400-2400 r/min |
| Engine Number Of Cylinders | 4 | Engine Displacement | 4.58 L |
| Transmission Model | HW90510C2 | Pto | yes |
| Forward Gears | 10 | Reverse Gears | 2 |
| Transmission Type | Manual | Front Axle | 3.6t (Drum Brake) |
| Rear Axle | 8.0t (Drum Brake) | Axle Gear Ratio | 4.333 |
| Tire Specification | 9.00R20 16PR | Fuel Tank Capacity | 200 L |
| Fuel Tank Type | Aluminum alloy tank | Electric System | 24 V |
| Brake Type | Front and rear drum brakes | Braking Method | Air brake, air cut-off brake, ABS |
| ③Upper-Body Specification |
| Tank Volume | 11000 L | Manhole | DN450 (18 inches) |
| Liquid Line | DN50 (2 inches) | Filling Hose | 14 m |
| Top Safety Rail | 1 set | Tank Shape | Oval or square (optional) |
| Water Pump (Self-priming) | QZ60/90, Yifeng or other Chinese brands, Flow 60 m³/h, Head 90 m | Dust Suppression Vehicle Tank Materials | Carbon steel or aluminum alloy or stainless steel |
| Tank Inside Treatment | Anti-corrosion and anti-rust | Front Spray Width | 16–20 m |
| Side Spray Width | 10–15 m | Rear Spray Width | 4–8 m |
| Dust Suppression Vehicle Other Equipment | Front direct spray / Rear sprinkling / Side watering / One hydrant connection | Dust Suppression Vehicle Mist Cannon Range | 80 m |
| Dust Suppression Vehicle Mist Cannon Horizontal Range | 100–120 m | Dust Suppression Vehicle Mist Cannon Fan Motor Power | 37 kW |
| Dust Suppression Vehicle Mist Cannon Operating Power | 11 kW | Dust Suppression Vehicle Mist Cannon Centrifugal Pump | Stainless steel multistage centrifugal pump |
| Dust Suppression Vehicle Mist Cannon Water Pump Flow | 170 L/min | Dust Suppression Vehicle Mist Cannon Vertical Spray Angle | -10° to +55° |
| Dust Suppression Vehicle Mist Cannon Horizontal Spray Angle | 0° to 360° | Dust Suppression Vehicle Mist Cannon Number Of Nozzles | 80 |
| Dust Suppression Vehicle Mist Cannon Atomization Fineness | 10–150 μm | Dust Suppression Vehicle Mist Cannon Filtration Accuracy | 250/60 μm/mesh |
| Dust Suppression Vehicle Mist Cannon Remote Control Distance | 100 m | Dust Suppression Vehicle Mist Cannon Generator Set Power | 120 kW |
