| Item | Parameter | Item | Parameter |
| ①Basic Info. | |||
| Overall Dimensions (L×W×H) | 101100 × 2550 × 3490 mm | Load Capacity | 20 / 25 tons |
| Transport Package | Bare painting and waxing treatment | Transportation | Ro-Ro / Bulk ship / Container vessel |
| Production Capacity | 100 units/month | Tare Weight | Approx. 9470 kg |
| Origin | Hubei, China | Delivery Time | Within 30 days |
| ②Chassis Specification | |||
| Chassis Brand | Shacman | Model | SX5255GYYMT464 |
| Drive Wheel | 6×4 | Wheelbase | 4575+1400 mm |
| Driving Position | LHD or RHD | Cabin Seats | 3 |
| Cabin Color | According to customer requirements | Engine Model | WP10.380E22 |
| Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification | Engine Rated Power | 280 kW |
| Engine Horsepower | 380 HP | Engine Max Torque | 1460 N·m @ 1200–1600 rpm |
| Engine Number Of Cylinders | 6 | Engine Displacement | 9.7 L |
| Transmission Model | 10JSD180T | Pto | yes |
| Forward Gears | 10 | Reverse Gears | 2 |
| Transmission Type | Manual | Synchronized | Yes |
| Front Axle | Load capacity 7.5 tons HD | Rear Axle | Load capacity 16 tons HD × 2 |
| Axle Gear Ratio | 16T HD double reduction cast axle, ratio 4.76 | Tire Specification | 12R22.5 all-position tread |
| Fuel Tank Capacity | 360 L | Fuel Tank Type | Aluminum alloy tank |
| Electric System | 24 V | Brake Type | Front and rear drum brakes |
| Braking Method | Air brake, air cut-off brake, ABS | Other Configurations | standard cab without roof spoiler, air suspension driver seat, bar-type side mirrors, air conditioning (single cooling), power windows, manual tilt cab, highway bumper, three-step cab access ladder, standard air filter, exhaust pipe with spark arrester, radiator grille guard, 165Ah maintenance-free battery, hydraulic cab suspension (4-point), ring-type curtains, cab rear window, SHACMAN badge, English-only markings, gold lettering & gold logo, steel air tanks, reverse alarm, transmission shift lever with extension, fuel tank (left side mounted), battery (left side mounted), external engine start/stop switch, compressor with Jacel technology, 32T jack |
| ③Upper-Body Specification | |||
| Water Tank Volume | 15 cbm | Mixer Capacity | 12 cbm |
| Surplus Ratio | ≤0.5% | Tanker Material | 16MnQ345 Carbon Steel |
| Drum Thickness | 6 mm | Blade Thickness | 4 mm |
| Filling Rate | 0.59 | Input Speed | ≥2.8 m³/min |
| Output Speed | ≥1.2 m³/min | Tanker Rotate Speed | 0–17 rpm |
| Hydraulic Pump | Chinese local GPC4-50-20-16 | Hydraulic Motor | Italy Brand: PMP |
| Speed Reducer | Germany Brand | Radiator | AH1012T (Hikeris brand) |
