| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 101100 × 2550 × 3490 mm | Load Capacity | 20 / 25 tons |
| Transport Package | Bare painting and waxing treatment | Transportation | Ro-Ro / Bulk ship / Container vessel |
| Production Capacity | 100 units/month | Tare Weight | Approx. 9470 kg |
| Origin | Hubei, China | Delivery Time | Within 30 days |
| ②Chassis Specification |
| Chassis Brand | Shacman | Model | SX5255GYYMT464 |
| Drive Wheel | 6×4 | Wheelbase | 4575+1400 mm |
| Cabin Model | H3000 | Driving Position | LHD or RHD |
| Cabin Seats | 3 | Cabin Color | According to customer requirements |
| Engine Model | WP10.380E22 | Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification |
| Engine Rated Power | 280 kW | Engine Horsepower | 380 HP |
| Engine Max Torque | 1460 N·m @ 1200–1600 rpm | Engine Number Of Cylinders | 6 |
| Engine Displacement | 9.7 L | Transmission Model | 10JSD180T |
| Pto | yes | Forward Gears | 10 |
| Reverse Gears | 2 | Transmission Type | Manual |
| Synchronized | Yes | Front Axle | Load capacity 7.5 tons HD |
| Rear Axle | Load capacity 16 tons HD × 2 | Axle Gear Ratio | 16T HD double reduction cast axle, ratio 4.76 |
| Tire Specification | 12R22.5 all-position tread | Fuel Tank Capacity | 360 L |
| Fuel Tank Type | Aluminum alloy tank | Electric System | 24 V |
| Brake Type | Front and rear drum brakes | Braking Method | Air brake, air cut-off brake, ABS |
| Other Configurations | H3000 standard cab without roof spoiler, air suspension driver seat, bar-type side mirrors, air conditioning (single cooling), power windows, manual tilt cab, highway bumper, three-step cab access ladder, standard air filter, exhaust pipe with spark arrester, radiator grille guard, 165Ah maintenance-free battery, hydraulic cab suspension (4-point), ring-type curtains, cab rear window, SHACMAN badge, English-only markings, gold lettering & gold logo, steel air tanks, reverse alarm, transmission shift lever with extension, fuel tank (left side mounted), battery (left side mounted), external engine start/stop switch, compressor with Jacel technology, 32T jack | | |
| ③Upper-Body Specification |
| Tank Volume | 25000 L | Manhole | DN450 (18 inches) |
| Liquid Line | DN50 (2 inches) | Filling Hose | 15 m |
| Top Safety Rail | 1 set | Water Sprinkler Truck Tank Materials | Carbon steel or aluminum alloy or stainless steel |
| Water Sprinkler Truck Dished Head Thickness | 5 mm | Tank Shape | Oval or square (optional) |
| Water Pump (Self-priming) | QZ60/90, Yifeng or other Chinese brands, Flow 60 m³/h, Head 90 m | Water Sprinkler Truck Other Equipment | Front flush, rear spray, side sprinklers, rear working platform with water cannon, one fire hydrant interface |
