| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 9100 × 2550 × 3260 mm | Load Capacity | 13 / 15 tons |
| Transport Package | Bare painting and waxing treatment | Transportation | Ro-Ro / Bulk ship / Container vessel |
| Production Capacity | 100 units/month | Tare Weight | Approx. 7990 kg |
| Origin | Hubei, China | Delivery Time | Within 30 days |
| ②Chassis Specification |
| Chassis Brand | Shacman | Drive Wheel | 4×2 |
| Wheelbase | 4500 mm | Cabin Model | L3000 |
| Driving Position | LHD or RHD | Cabin Seats | 3 |
| Cabin Color | According to customer requirements | Engine Model | YCS04200-68 |
| Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification | Engine Rated Power | 147 kW |
| Engine Horsepower | 200 HP | Engine Number Of Cylinders | 4 |
| Engine Displacement | 4.156 L | Transmission Model | 8JS85TE-C |
| Pto | yes | Forward Gears | 8 |
| Reverse Gears | 2 | Transmission Type | Manual |
| Synchronized | Yes | Transmission Gear Ratios | Forward: 9.65, 6.46, 4.32, 3.19, 2.23, 1.50, 1.00, 0.74; Reverse: 9.81, 2.27 |
| Front Axle | Load capacity 6 T | Rear Axle | 10 T |
| Tire Specification | 10.00R20 | Fuel Tank Capacity | 160 L |
| Fuel Tank Type | Aluminum alloy tank | Electric System | 24 V |
| Brake Type | Front and rear drum brakes | Braking Method | Air brake, air cut-off brake, ABS |
| ③Upper-Body Specification |
| Tank Volume | 13000 L | Tank Shape | Oval or square (optional) |
| Water Pump (Self-priming) | QZ60/90, Yifeng or other Chinese brands, Flow 60 m³/h, Head 90 m | Manhole | DN450 (18 inches) |
| Liquid Line | DN50 (2 inches) | Filling Hose | 15 m |
| Top Safety Rail | 1 set | Dust Suppression Vehicle Tank Materials | Carbon steel or aluminum alloy or stainless steel |
| Tank Inside Treatment | Anti-corrosion and anti-rust | Front Spray Width | 16–20 m |
| Side Spray Width | 10–15 m | Rear Spray Width | 4–8 m |
| Dust Suppression Vehicle Other Equipment | Front direct spray / Rear sprinkling / Side watering / One hydrant connection | Dust Suppression Vehicle Mist Cannon Range | 80 m |
| Dust Suppression Vehicle Mist Cannon Horizontal Range | 100–120 m | Dust Suppression Vehicle Mist Cannon Fan Motor Power | 37 kW |
| Dust Suppression Vehicle Mist Cannon Operating Power | 11 kW | Dust Suppression Vehicle Mist Cannon Centrifugal Pump | Stainless steel multistage centrifugal pump |
| Dust Suppression Vehicle Mist Cannon Water Pump Flow | 170 L/min | Dust Suppression Vehicle Mist Cannon Vertical Spray Angle | -10° to +55° |
| Dust Suppression Vehicle Mist Cannon Horizontal Spray Angle | 0° to 360° | Dust Suppression Vehicle Mist Cannon Number Of Nozzles | 80 |
| Dust Suppression Vehicle Mist Cannon Atomization Fineness | 10–150 μm | Dust Suppression Vehicle Mist Cannon Filtration Accuracy | 250/60 μm/mesh |
| Dust Suppression Vehicle Mist Cannon Remote Control Distance | 100 m | Dust Suppression Vehicle Mist Cannon Generator Set Power | 120 kW |
