| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 9101 × 2550 × 3260 mm | Load Capacity | 10 / 15 tons |
| Transport Package | Bare painting and waxing treatment | Transportation | Ro-Ro / Bulk ship / Container vessel |
| Production Capacity | 100 units/month | Tare Weight | Approx. 7990 kg |
| Origin | Hubei, China | Delivery Time | Within 30 days |
| ②Chassis Specification |
| Chassis Brand | Shacman | Drive Wheel | 4×2 |
| Wheelbase | 4500 mm | Cabin Model | F3000 |
| Driving Position | LHD or RHD | Cabin Seats | 3 |
| Cabin Color | According to customer requirements | Engine Model | ISM11E5 345 |
| Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification | Engine Rated Power | 254 kW |
| Engine Horsepower | 345 HP | Engine Max Torque | 1800 N·m |
| Engine Number Of Cylinders | 6 | Engine Displacement | 10.8 L |
| Transmission Model | 10JSD180T | Pto | QH50 |
| Forward Gears | 10 | Reverse Gears | 2 |
| Transmission Type | Manual | Synchronized | Yes |
| Front Axle | Load capacity 6 T | Rear Axle | 10 T |
| Tire Specification | 10.00R20 | Fuel Tank Capacity | 160 L |
| Fuel Tank Type | Aluminum alloy tank | Electric System | 24 V |
| Brake Type | Front and rear drum brakes | Braking Method | Air brake, air cut-off brake, ABS |
| ③Upper-Body Specification |
| Tank Volume | 10000 L | Water Sprinkler Truck Tank Materials | Carbon steel or aluminum alloy or stainless steel |
| Water Sprinkler Truck Dished Head Thickness | 5 mm | Tank Shape | Oval or square (optional) |
| Water Pump (Self-priming) | QZ60/90, Yifeng or other Chinese brands, Flow 60 m³/h, Head 90 m | Water Sprinkler Truck Other Equipment | Front flush, rear spray, side sprinklers, rear working platform with water cannon, one fire hydrant interface |
| Manhole | DN450 (18 inches) | Liquid Line | DN50 (2 inches) |
| Filling Hose | 15 m | Top Safety Rail | 1 set |
