| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 12100 × 2500 × 3800 mm | Load Capacity | 35 / 50 tons |
| Transport Package | Bare painting and waxing treatment | Transportation | Ro-Ro / Bulk ship / Container vessel |
| Production Capacity | 100 units/month | Tare Weight | Approx. 9900 kg |
| Origin | Hubei, China | Delivery Time | Within 30 days |
| ②Chassis Specification |
| Main Beams | Steel Q345B or aluminum alloy | Kingpin | 2" or 3.5", brand optional |
| Braking System | RE6 relay valve, spring brake chamber, 2 pieces of 45 L air tanks | Tire | 12.00R20 / 315/80R22.5, brand optional |
| Spare Tire Carrier | 2 pieces | ABS System | Optional |
| Tool Box | 1 piece standard | Fire Extinguisher | 2 pieces |
| Axle | 13T/16T, FUWA/BPW brand (manual operation not applicable) | Suspension | Mechanical suspension / Air suspension |
| Leaf Spring | 90 mm (W) × 13 mm (T) × 10 layers or 100 mm × 12 mm × 12 layers | Landing Gear | JOST (D200T) or Chinese brand 28T (two-speed) |
| Rim | 9.00-22.5 / 8.0-20 / 8.5-20 | Safety Guard | Standard |
| Lights | LED, 24V | Painting | Complete chassis sandblasting to remove rust, 1 coat of anti-corrosion primer, 2 coats of top paint |
| ③Upper-Body Specification |
| Tank Thickness | Carbon steel shell 5 mm, ends 6 mm, inner PE layer 18 mm | Tank Shape | Oval or square (optional) |
| Garbage Compactor Truck Tank Materials | Q235 carbon steel (special steel) | Tank Design | Integral leak-proof design |
| Unloading Time | ≤45 s | Control Mode | Electric/Manual/Remote (three modes standard) |
| Engine Power Control | Fully automatic | Max Hydraulic System Pressure | 20 MPa |
| Manufacturing Process | Whole plate forming | Control System | PLC |
| Compaction Ratio | 1:3 to 1:4 | Control Panel Language | English or as requested |
| Garbage Compactor Truck Hopper Effective Volume | ≥0.8 m³ | Standard Accessories | Dustbin lifter, ladder, warning lights, emergency stop button, handrail, fire extinguisher, basic tool kit, English manual |
| Loading Method | Rear loading, optional bin lifting system | Optional | Rear view camera and backup alarm; Italian multi-way valve; 240L (single or double bin) or standard 660L/1100L bins with bin lifter |
