| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Tare Weight | 4500 kg | Transport Package | Bare painting and waxing treatment |
| Transportation | Ro-Ro / Bulk ship / Container vessel | Delivery Time | Within 30 days |
| Production Capacity | 100 units/month | Origin | Hubei, China |
| Delivery Time | Within 30 days | | |
| ③Upper-Body Specification |
| Tank Volume | 5000–20000 L | Tank Material | High strength and wear-resistant steel |
| Shell Thickness | 8 mm | Working Pressure | 16 MPa |
| Design Code | ASME VIII Div.1 / IMDG CODE / CSC / TC / ADR / TPED / ISO 1496-3 / GB/T 16563 | Head Thickness | 8 mm |
| Test Pressure | Hydraulic: 2.7 MPa, Pneumatic: 2.07 MPa | Design Temperature Range | -40°C to +130°C |
| Frame Material | Q345B / Corten Steel | Stacking Load Capacity | 216000 kg |
| Portable Tank Type | IMO Type 5 / UN Portable Tank | Insulation Type | Vacuum insulated / Mineral wool / None |
| Bottom Discharge Valve | DN80, Stainless Steel, with Emergency Shut-off | Top Filling Lid | DN500, Stainless Steel, with Pressure/Vacuum Vent |
| Safety Valve | 2 pcs, Full Lift Type, Set Pressure 2.0 MPa | Pressure Gauge | Φ100 mm, 0–4 MPa, Stainless Steel Case |
| Thermometer | Pt100 Sensor with Local Display | Level Gauge | Magnetic Level Indicator with Remote Transmission |
| Steam Heating System | Stainless Steel Heating Coils Inside Tank, Heating Area 8 m² | External Steam Inlet | DN40, Quick Coupling |
| Certificate Of Approval | UN Portable Tank Certificate / CSC Plate / TC Approval / TPED Certificate | Port Of Loading | Shanghai, China |
| Production Capacity | 100 units/month | | |
