| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 5990 × 2050 × 2550 mm | Load Capacity | 5 tons |
| Transport Package | Bare painting and waxing treatment | Transportation | Ro-Ro / Bulk ship / Container vessel |
| Production Capacity | 100 units/month | Tare Weight | Approx. 3970 kg |
| Origin | Hubei, China | Delivery Time | Within 30 days |
| ②Chassis Specification |
| Chassis Brand | JMC | Model | QL1042BUHAY |
| Drive Wheel | 4×2 | Wheelbase | 3360 mm |
| Driving Position | LHD or RHD | Cabin Seats | 3 |
| Cabin Color | According to customer requirements | Engine Model | 4KB1-TCG60 |
| Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification | Engine Rated Power | 96 kW |
| Engine Horsepower | 130 HP | Engine Max Torque | 350 N·m @ 2900-3400 rpm |
| Engine Number Of Cylinders | 4 | Engine Displacement | 2.5 L |
| Transmission Model | MSB 5-Speed | Pto | yes |
| Forward Gears | 5 | Reverse Gears | 1 |
| Transmission Type | Manual | Front Axle | Load capacity 2.5 tons |
| Rear Axle | 4.8 tons | Tire Specification | 7.00R16LT 8PR |
| Electric System | 24 V | Brake Type | Front and rear drum brakes |
| Braking Method | Air brake, air cut-off brake, ABS | Other Configurations | Air conditioning with heating and cooling, power steering, central locking, power windows, multifunction LCD instrument panel, ABS, air brake (or hydraulic brake), tilting cab. |
| ③Upper-Body Specification |
| Maximum Operating Height | 24m | Control System | Electro-hydraulic proportional control system and optional load proportional system can realize double action synchronization and speed regulation |
| Leveling System | Hydraulic automatic leveling | Rotation | 360° |
| Automatic Interlocking Device For Up And Down | For locking up and down the truck to prevent the risk of incorrect operation | Boom Type | Telescopic boom |
| Basket | 360-degree rotation | Outrigger Type | Front V Rear H type. Controlled independently |
| Horizontal Function | Real-time display | Outrigger Span | Vertical-4000mm/Horizontal-4350mm |
| Real Time Communication | There is a wireless intercom between the platform and the vehicle | Operation Mode | 4 operation modes; Electrical operation of the working platform; Ground remote control; Controller in the bucket |
| Emergency Lever | Emergency Electric Emergency Pump. When the engine and main pump fail, the emergency electric pump can be operated to ensure the operator can be sent to the ground. | | |
