| Item | Parameter | Item | Parameter |
| ①Basic Info. | |||
| Overall Dimensions (L×W×H) | 7000 × 2350 × 2750 mm | Load Capacity | 8 / 12 tons |
| Transport Package | Bare painting and waxing treatment | Transportation | Ro-Ro / Bulk ship / Container vessel |
| Production Capacity | 100 units/month | Tare Weight | Approx. 5100 kg |
| Origin | Hubei, China | Delivery Time | Within 30 days |
| ②Chassis Specification | |||
| Chassis Brand | FAW Jiefang | Drive Wheel | 4×2 |
| Wheelbase | 3800 mm | Driving Position | LHD or RHD |
| Cabin Seats | 3 | Cabin Color | According to customer requirements |
| Engine Model | YN38CRD1 | Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification |
| Engine Rated Power | 95 kW | Engine Horsepower | 129 HP |
| Engine Max Torque | 365 N·m / 1600-2400 r/min | Engine Number Of Cylinders | 6 |
| Engine Displacement | 3.76 L | Transmission Model | WLY6TS55 |
| Pto | yes | Forward Gears | 6 |
| Reverse Gears | 1 | Transmission Type | Manual |
| Synchronized | Yes | Transmission Gear Ratios | 12.1 / 9.41 / 7.31 / 5.71 / 4.46 / 3.48 / 2.71 / 2.11 / 1.64 / 1.28 / 1.0 / 0.78, Reverse 11.56, Reverse 2 2.59 |
| Front Axle | 2.7T | Rear Axle | 7.2T |
| Axle Gear Ratio | 5.286 | Tire Specification | 8.25R16 |
| Fuel Tank Capacity | 120 L | Fuel Tank Type | Aluminum alloy tank |
| Electric System | 24 V | Brake Type | Front and rear drum brakes |
| Braking Method | Air brake, air cut-off brake, ABS | ||
| ③Upper-Body Specification | |||
| Tank Volume | 10000 L | Fresh Milk Delivery Vehicle Tank Materials | SUS304-2B food grade |
| Fresh Milk Delivery Vehicle Dished Head Thickness | 6 mm | Fresh Milk Delivery Vehicle Number Of Compartments | 2 to 6 compartments, or customized as required |
| Emergency Bottom Valve | Aluminum alloy / Stainless steel | Discharging Valve | 3", 4" or 6" diameter |
| Pump | YHCB/80/60, 50 m³/h | Manhole | DN450 (18 inches) |
| Liquid Line | DN50 (2 inches) | Filling Hose | 15 m |
| Top Safety Rail | 1 set | Casing Thickness | 61 mm |
| Fresh Milk Delivery Vehicle Insulation Material | 70 mm polyurethane spray coating + 10 mm rubber and plastic insulation cotton | Fresh Milk Delivery Vehicle Tank Head Thickness | Single-layer butterfly end cap thickness 3 mm |
| Fresh Milk Delivery Vehicle Milk Outlet Diameter | 51 mm (standard/non-standard) | Fresh Milk Delivery Vehicle Cleaning Method | CIP automatic cleaning system, each compartment equipped with a cleaning ball for 360° cleaning |
| Fresh Milk Delivery Vehicle Other Features | 1. The milk dispensing and cleaning switches are bundled together and labeled with the number of each milk compartment. Before leaving the factory, the tank body is painted with the transport medium and the announced volume as required by the announcement. 2. The rear control box uses a gas spring hinged opening and is equipped with an opening handle. 3. Each manhole cover and rear toolbox is equipped with a lead seal device for easy management when loading and unloading fresh milk. 4. A movable ladder is provided for personnel to enter and exit the tank. 5. Three compartments are evenly distributed [customizable], with two tension support plates and three 500 mm food-grade tank openings. 6. Each compartment has two automatic cleaning balls controlled by three valves with 51 mm valve interfaces. | ||
