| Item | Parameter | Item | Parameter |
| ①Basic Info. | |||
| Overall Dimensions (L×W×H) | 5990 × 2050 × 2550 mm | Load Capacity | 5 tons |
| Transport Package | Bare painting and waxing treatment | Transportation | Ro-Ro / Bulk ship / Container vessel |
| Production Capacity | 100 units/month | Tare Weight | Approx. 3970 kg |
| Origin | Hubei, China | Delivery Time | Within 30 days |
| ②Chassis Specification | |||
| Chassis Brand | ISUZU | Model | QL1042BUHAY |
| Drive Wheel | 4×4 | Wheelbase | 3360 mm |
| Cabin Model | 3X 700 | Driving Position | LHD or RHD |
| Cabin Seats | 3 | Cabin Color | According to customer requirements |
| Engine Model | 4KB1-TCG60 | Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification |
| Engine Rated Power | 96 kW | Engine Horsepower | 130 HP |
| Engine Max Torque | 350 N·m @ 2900-3400 rpm | Engine Number Of Cylinders | 4 |
| Engine Displacement | 2.5 L | Transmission Model | MSB 5-Speed |
| Pto | yes | Forward Gears | 5 |
| Reverse Gears | 1 | Transmission Type | Manual |
| Front Axle | Load capacity 2.5 tons | Rear Axle | 4.8 tons |
| Tire Specification | 7.00R16LT 8PR | Electric System | 24 V |
| Brake Type | Front and rear drum brakes | Braking Method | Air brake, air cut-off brake, ABS |
| Other Configurations | Air conditioning with heating and cooling, power steering, central locking, power windows, multifunction LCD instrument panel, ABS, air brake (or hydraulic brake), tilting cab. | ||
| ③Upper-Body Specification | |||
| Tank Materials | Carbon steel or stainless steel | Fire Pump Model | CB40.10/7.50 |
| Fire Pump Low Pressure Working | 10 bar, 300 L/min | Fire Pump High Pressure Working | 40 bar, 350 L/min |
| Fire Pump Max Suction Height | 7 m | Fire Pump Rated Speed | 3000 r/min |
| Fire Pump Time Of Drawing Water | ≤35 s | Fire Pump Input Diameter | 125 mm |
| Fire Pump Outlet Diameter | 4 × Φ65 mm | Fire Fighting Monitor Model | PL48 |
| Fire Fighting Monitor Range | ≥65 m | Fire Fighting Monitor Flow | 2400 L/min |
| Fire Fighting Monitor Rated Working Pressure | 0.7–1.2 MPa | Fire Fighting Monitor Rotation Angle | 360° |
| Fire Fighting Monitor Elevation Angle | ≥80° | Fire Fighting Monitor Depression Angle | ≤–30° |
| Standard Configuration | 1. Alarm rotating light mounted on top of the cabin 2. Two side lights per side (four in each side) plus rear pump working lights 3. Two ladders on rear left and right side of the tank 4. Manhole 5. Two 60m high-pressure hose reels 6. All piping manufactured from stainless steel 7. CB10/60 centrifugal pump and PL48 manual monitor 8. Standard inlets and discharge couplings, all BS model with blind caps 9. Telescopic lighting, powered 220V by diesel generator | ||
