| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 5990 × 2050 × 2550 mm | Load Capacity | 5 tons |
| Transport Package | Bare painting and waxing treatment | Transportation | Ro-Ro / Bulk ship / Container vessel |
| Production Capacity | 100 units/month | Tare Weight | Approx. 3970 kg |
| Origin | Hubei, China | Delivery Time | Within 30 days |
| ②Chassis Specification |
| Chassis Brand | ISUZU | Model | QL1042BUHAY |
| Drive Wheel | 4×2 | Wheelbase | 3360 mm |
| Cabin Model | 3X 700 | Driving Position | LHD or RHD |
| Cabin Seats | 3 | Cabin Color | According to customer requirements |
| Engine Model | 4KB1-TCG60 | Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification |
| Engine Rated Power | 96 kW | Engine Horsepower | 130 HP |
| Engine Max Torque | 350 N·m @ 2900-3400 rpm | Engine Number Of Cylinders | 4 |
| Engine Displacement | 2.5 L | Transmission Model | MSB 5-Speed |
| Pto | yes | Forward Gears | 5 |
| Reverse Gears | 1 | Transmission Type | Manual |
| Front Axle | Load capacity 2.5 tons | Rear Axle | 4.8 tons |
| Tire Specification | 7.00R16LT 8PR | Electric System | 24 V |
| Brake Type | Front and rear drum brakes | Braking Method | Air brake, air cut-off brake, ABS |
| Other Configurations | Air conditioning with heating and cooling, power steering, central locking, power windows, multifunction LCD instrument panel, ABS, air brake (or hydraulic brake), tilting cab. | | |
| ③Upper-Body Specification |
| Dc Battery Voltage Range | 500V~850Vdc-500V | Dc Max Input Current | 550A or 1100A |
| Dc Rated Output Power | 250kW or 500kW | Output Wire Connection | 3W+N+PE |
| Output Rated Voltage | 400Vac | Rated Output Current | 361A or 722A |
| Output Isolation Method | Transformer | Grid Connected Voltage Range | 400Vac(-20%~+10%) |
| Grid Connected Frequency Range | 50±5Hz/60±5Hz | Grid Connected Overload Capacity | 110% for 10 minutes, 120% for 1 minute |
| Grid Connected Thdi | ≤3% | Grid Connected Power Factor | -0.99(lagging)~ +0.99(leading) |
| Rated Voltage | 400V | Grid Voltage Range | 400VAC±10% |
| Grid Frequency Range | 50Hz/60Hz | Off Grid Integrated With Unbalanced Load Capacity | ≤100% |
| Off Grid Thdi | ≤3%(Pure resistive load) | Off Grid Overload Capacity | 110% for 10 minutes, 120% for 1 minute |
| Working Environment Temperature | -15°C~50°C | Max Working Temperature Range | -20°C~55°C |
| Ideal Working Temperature Range | 20°C~30°C | Altitude | ≤4000m (over 2000m the capacity will be degraded) |
