| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 5600 × 2200 × 2350 mm | Load Capacity | 2 / 5 tons |
| Transport Package | Bare painting and waxing treatment | Transportation | Ro-Ro / Bulk ship / Container vessel |
| Production Capacity | 100 units/month | Tare Weight | Approx. 2830 kg |
| Origin | Hubei, China | Delivery Time | Within 30 days |
| ②Chassis Specification |
| Chassis Brand | foton | Drive Wheel | 4×2 |
| Wheelbase | 3000 mm | Driving Position | LHD or RHD |
| Cabin Seats | 3 | Cabin Color | According to customer requirements |
| Engine Model | Q23-132E60 | Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification |
| Engine Rated Power | 97 kW | Engine Horsepower | 131 HP |
| Engine Number Of Cylinders | 4 | Engine Displacement | 2.3 L |
| Transmission Model | WLY6TS55 | Pto | yes |
| Forward Gears | 6 | Reverse Gears | 1 |
| Transmission Type | Manual | Front Axle | Load capacity 2 T |
| Rear Axle | 3.5 T | Tire Specification | 6.50 |
| Fuel Tank Capacity | 100 L | Fuel Tank Type | Steel fuel tank |
| Electric System | 24 V | Brake Type | Front and rear drum brakes |
| Braking Method | Air brake, air cut-off brake, ABS | | |
| ③Upper-Body Specification |
| Model Of Asphalt Pump | QGB950 (950L/min) | Origin Of Asphalt Pump | China Made |
| Suitable Tank Volume | 3 CBM | Medium | Hot/Dilute/Emulsify Asphalt |
| Hydraulic System | Shanxi YUCI | Proportional Valve | EFBG-03-160-HF (Taiwan) |
| Reversing Valve | SWH-G03-D24-20 (Northman) | Model Of Hydraulic Pump | CBQ550-L |
| Model Of Hydraulic Motor | 05-110-BD31 | Radiator | AH1012T (Hikeris brand) |
| Control System | Electro-hydraulic proportional control system and optional load proportional system can realize double action synchronization and speed regulation | Control Type | 1-control-1 |
| Operation Person | 2 persons | Asphalt Nozzle Number | 36 pcs pneumatic nozzles |
| Heating Type | Heat conducting oil automatically heating | Conducting Oil | Hebei, China |
| Burner | Italy import G20 | Power Of Engine | 6 kW |
| Spraying Capacity | 0.25–3.5 L/min | Spraying Width | 4.5 m (6 m optional) |
