| Item | Parameter | Item | Parameter |
| ①Basic Info. | |||
| Overall Dimensions (L×W×H) | 6950 × 2350 × 2850 mm | Load Capacity | 8 / 12 tons |
| Transport Package | Bare painting and waxing treatment | Transportation | Ro-Ro / Bulk ship / Container vessel |
| Production Capacity | 100 units/month | Tare Weight | Approx. 5130 kg |
| Origin | Hubei, China | Delivery Time | Within 30 days |
| ②Chassis Specification | |||
| Chassis Brand | foton | Drive Wheel | 4×2 |
| Wheelbase | 3800 mm | Driving Position | LHD or RHD |
| Cabin Seats | 3 | Cabin Color | According to customer requirements |
| Engine Model | F3.8NS6B156 | Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification |
| Engine Rated Power | 115 kW | Engine Horsepower | 156 HP |
| Engine Number Of Cylinders | 4 | Engine Displacement | 3.8 L |
| Transmission Model | WLY6TS55 | Pto | yes |
| Forward Gears | 6 | Reverse Gears | 1 |
| Transmission Type | Manual | Front Axle | Load capacity 3.5 T |
| Rear Axle | 6.5 T | Tire Specification | 825R16 |
| Fuel Tank Capacity | 120 L | Fuel Tank Type | Steel fuel tank |
| Electric System | 24 V | Brake Type | Front and rear drum brakes |
| Braking Method | Air brake, air cut-off brake, ABS | ||
| ③Upper-Body Specification | |||
| Box Material | Stainless steel interior, outer fiberglass; base plate: stainless steel full weld | Box Dimensions | 5800×2500×2600 mm |
| Box Structure | 3 or 4 layers, with openable and closable side windows | Loading Area Per Layer | 4 layers: 14.2 m²; 3 layers: 14.2 m² |
| Capacity Unit | 14.2 m² × 3 layers / 70 heads / 125 kg per head (for 3-layer model) | Layer Height | 850 mm (3 layers), 620 mm (4 layers) |
| Reversible Structural Components | Middle aisle floor, top plate | Loading And Unloading Method | Hydraulic vertical lifting tailgate |
| Tailgate Area | 5 m² | Cooling System | 18 spray nozzles / 3 layers |
| Feeding System | 18 drinking nozzles / 3 layers | Fan Air Flow | 500, 1200, 1400, 2200 m³/h |
| Standard Configuration | 1. Alarm rotating light mounted on top of the cabin 2. Two side lights per side (four in each side) plus rear pump working lights 3. Two ladders on rear left and right side of the tank 4. Manhole 5. Two 60m high-pressure hose reels 6. All piping manufactured from stainless steel 7. CB10/60 centrifugal pump and PL48 manual monitor 8. Standard inlets and discharge couplings, all BS model with blind caps 9. Telescopic lighting, powered 220V by diesel generator | ||
