| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 8380 × 2550 × 3220 mm | Load Capacity | 15 tons |
| Transport Package | Bare painting and waxing treatment | Transportation | Ro-Ro / Bulk ship / Container vessel |
| Production Capacity | 100 units/month | Tare Weight | Approx. 6660 kg |
| Origin | Hubei, China | Delivery Time | Within 30 days |
| ②Chassis Specification |
| Chassis Brand | foton | Model | BJ1164VKPFA-01 |
| Drive Wheel | 4×2 | Wheelbase | 4500 mm |
| Driving Position | LHD or RHD | Cabin Seats | 3 |
| Cabin Color | According to customer requirements | Engine Model | WP4.1NQ190E61 |
| Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification | Engine Rated Power | 140 kW |
| Engine Horsepower | 190 HP | Engine Number Of Cylinders | 4 |
| Engine Displacement | 4.088 L | Transmission Model | 8JS85TE-C |
| Pto | yes | Forward Gears | 8 |
| Reverse Gears | 2 | Transmission Type | Manual |
| Synchronized | Yes | Transmission Gear Ratios | Forward: 9.65, 6.46, 4.32, 3.19, 2.23, 1.50, 1.00, 0.74; Reverse: 9.81, 2.27 |
| Front Axle | Load capacity 6 tons | Rear Axle | Load capacity 10 tons |
| Tire Specification | 10R22.5 16PR | Fuel Tank Capacity | 160 L |
| Fuel Tank Type | Aluminum alloy tank | Electric System | 24 V |
| Brake Type | Front and rear drum brakes | Braking Method | Air brake, air cut-off brake, ABS |
| ③Upper-Body Specification |
| Tank Volume | 15000 L | Water Sprinkler Truck Tank Materials | Carbon steel or aluminum alloy or stainless steel |
| Water Sprinkler Truck Dished Head Thickness | 5 mm | Tank Shape | Oval or square (optional) |
| Water Pump (Self-priming) | QZ60/90, Yifeng or other Chinese brands, Flow 60 m³/h, Head 90 m | Water Sprinkler Truck Other Equipment | Front flush, rear spray, side sprinklers, rear working platform with water cannon, one fire hydrant interface |
| Manhole | DN450 (18 inches) | Liquid Line | DN50 (2 inches) |
| Filling Hose | 15 m | Top Safety Rail | 1 set |
