| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 8450 × 2500 × 3200 mm | Transport Package | Bare painting and waxing treatment |
| Transportation | Ro-Ro / Bulk ship / Container vessel | Production Capacity | 100 units/month |
| Tare Weight | Approx. 12800 kg | Origin | Hubei, China |
| Delivery Time | Within 30 days | | |
| ②Chassis Specification |
| Chassis Brand | FAW Jiefang | Drive Wheel | 4×2 |
| Wheelbase | 4700 mm | Driving Position | LHD or RHD |
| Cabin Seats | 3 | Cabin Color | According to customer requirements |
| Engine Model | YC6J240-33 | Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification |
| Engine Rated Power | 176 kW | Engine Horsepower | 240 HP |
| Engine Max Torque | 1460 N·m @ 1200–1600 rpm | Engine Number Of Cylinders | 6 |
| Engine Displacement | 9.7 L | Transmission Model | 8JS85TE-C |
| Pto | yes | Forward Gears | 8 |
| Reverse Gears | 2 | Transmission Type | Manual |
| Synchronized | Yes | Transmission Gear Ratios | Forward: 10.36, 6.30, 4.32, 3.43, 2.41, 1.46, 1.00, 0.79; Reverse: 10.53, 2.44 |
| Front Axle | Load capacity 5 tons | Rear Axle | Load capacity 10 tons |
| Axle Gear Ratio | Single reduction, ratio 5.571 | Tire Specification | 10.00R20 18PR |
| Fuel Tank Capacity | 220 L | Fuel Tank Type | Aluminum alloy tank |
| Electric System | 24 V | Brake Type | Front and rear drum brakes |
| Braking Method | Air brake, air cut-off brake, ABS | | |
| ③Upper-Body Specification |
| Wrecker Type | integrated | Integrated Wrecker Body Type | 25T integrated tow truck body |
| Integrated Wrecker Main Boom Type | Two-section hexagonal boom | Integrated Wrecker Tow Boom Type | Three-section tow boom |
| Integrated Wrecker Underlift Structure | Reinforced | Integrated Wrecker Vertical Boom Structure | Reinforced |
| Integrated Wrecker Cabin Type | Split-type cabin | Integrated Wrecker Operation | Dual-side linked control |
| Integrated Wrecker Wheel Lift Device | Equipped | Integrated Wrecker Warning Lights | Equipped |
| Integrated Wrecker Auxiliary Braking | 1 set of air pipe assembly | Integrated Wrecker Remote Control | Triple wireless remote control |
| Integrated Wrecker Valves | Imported Italian HYDAC valves | Integrated Wrecker Hydraulic Pump | Wanii dual-pump |
| Integrated Wrecker Structural Reinforcement | Reinforced stress-bearing parts | Integrated Wrecker Cabin Surface Treatment | Electrophoresis |
| Integrated Wrecker Accessories | 4 pairs of Y-type forks + 1 movable fork | Integrated Wrecker Lashing Chains | 2 pieces |
| Integrated Wrecker Underlift Fork Seats | 2 sets | | |
