| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 8450 × 2500 × 3200 mm | Transport Package | Bare painting and waxing treatment |
| Transportation | Ro-Ro / Bulk ship / Container vessel | Production Capacity | 100 units/month |
| Tare Weight | Approx. 7410 kg | Origin | Hubei, China |
| Delivery Time | Within 30 days | | |
| ②Chassis Specification |
| Chassis Brand | Dongfeng | Model | DFL1140B2-KG2E-952-012J |
| Drive Wheel | 4×2 | Wheelbase | 4500 mm |
| Driving Position | LHD or RHD | Cabin Seats | 3 |
| Cabin Color | According to customer requirements | Engine Model | Cummins B210 33 |
| Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification | Engine Rated Power | 154 kW |
| Engine Horsepower | 210 HP | Engine Max Torque | 700 N·m @ 1200–1800 rpm |
| Engine Number Of Cylinders | 6 | Engine Displacement | 5.9 L |
| Transmission Model | 8JS85TE-C | Pto | yes |
| Forward Gears | 8 | Reverse Gears | 2 |
| Transmission Type | Manual | Synchronized | Yes |
| Transmission Gear Ratios | Forward: 9.65, 6.46, 4.32, 3.19, 2.23, 1.50, 1.00, 0.74; Reverse: 9.81, 2.27 | Front Axle | Load capacity 6 tons |
| Rear Axle | Load capacity 10 tons | Axle Gear Ratio | Single reduction, ratio 5.29 |
| Tire Specification | 10.00R20 | Fuel Tank Capacity | 160 L |
| Fuel Tank Type | Steel fuel tank | Electric System | 24 V |
| Brake Type | Front and rear drum brakes | Braking Method | Air brake, air cut-off brake, ABS |
| ③Upper-Body Specification |
| Dumpster Volume | 7 cbm (stainless steel) | Cleaning System Main Components | Sweep disk support, sweep disk, oil cylinder, oil pipe, connecting rod, adjusting rod, hydraulic motor, etc. |
| Clear Water Tank Volume | 9 m³ (stainless steel) | Disk Motor Speed | 140 r/min |
| Cleaning Width | 2800–3200 mm | Number Of Sweep Disks | 2 pieces |
| Cleaning Operation Speed | 15–20 km/h | Brushes Per Sweep Disk | 22 pieces |
| Suction Ability | Density: 2.0 g/cm³; Cleaning operation time: 2–4 hours; Suction particle size: ≥100 mm | Sweep Disk Tilt Angle Adjustment | 5°–15° forward |
| Garbage Box Dump Angle | ≥45° | Water Spray Form | Low-pressure mist |
| Cleaning Efficiency | ≥96% | Main Components | Inlet high-pressure pump, water filter, pipeline, stainless steel nozzle, high-pressure nozzle, etc. |
| Operation Noise | | High Pressure Pump | German Pinfu |
| Auxiliary Engine | Model: B170, Brand: Cummins, Power: 170 HP | Installation Location | Dust collection: left and right front sweep plates; Dust suction and removal: inside the suction outlet of the suction cup |
