| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 8450 × 2500 × 3200 mm | Load Capacity | 11 / 15 tons |
| Transport Package | Bare painting and waxing treatment | Transportation | Ro-Ro / Bulk ship / Container vessel |
| Production Capacity | 100 units/month | Tare Weight | Approx. 7410 kg |
| Origin | Hubei, China | Delivery Time | Within 30 days |
| ②Chassis Specification |
| Chassis Brand | Dongfeng | Model | DFL1140B2-KG2E-952-012J |
| Drive Wheel | 4×2 | Wheelbase | 4500 mm |
| Driving Position | LHD or RHD | Cabin Seats | 3 |
| Cabin Color | According to customer requirements | Engine Model | Cummins B210 33 |
| Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification | Engine Rated Power | 154 kW |
| Engine Horsepower | 210 HP | Engine Max Torque | 700 N·m @ 1200–1800 rpm |
| Engine Number Of Cylinders | 6 | Engine Displacement | 5.9 L |
| Transmission Model | 8JS85TE-C | Pto | yes |
| Forward Gears | 8 | Reverse Gears | 2 |
| Transmission Type | Manual | Synchronized | Yes |
| Transmission Gear Ratios | Forward: 9.65, 6.46, 4.32, 3.19, 2.23, 1.50, 1.00, 0.74; Reverse: 9.81, 2.27 | Front Axle | Load capacity 6 tons |
| Rear Axle | Load capacity 10 tons | Axle Gear Ratio | Single reduction, ratio 5.29 |
| Tire Specification | 10.00R20 | Fuel Tank Capacity | 160 L |
| Fuel Tank Type | Steel fuel tank | Electric System | 24 V |
| Brake Type | Front and rear drum brakes | Braking Method | Air brake, air cut-off brake, ABS |
| ③Upper-Body Specification |
| Tank Thickness | Carbon steel shell 5 mm, ends 6 mm, inner PE layer 18 mm | Tank Shape | Oval or square (optional) |
| Garbage Compactor Truck Tank Materials | Q235 carbon steel (special steel) | Tank Design | Integral leak-proof design |
| Unloading Time | ≤45 s | Control Mode | Electric/Manual/Remote (three modes standard) |
| Engine Power Control | Fully automatic | Max Hydraulic System Pressure | 20 MPa |
| Manufacturing Process | Whole plate forming | Control System | PLC |
| Compaction Ratio | 1:3 to 1:4 | Control Panel Language | English or as requested |
| Garbage Compactor Truck Hopper Effective Volume | ≥0.8 m³ | Standard Accessories | Dustbin lifter, ladder, warning lights, emergency stop button, handrail, fire extinguisher, basic tool kit, English manual |
| Loading Method | Rear loading, optional bin lifting system | Optional | Rear view camera and backup alarm; Italian multi-way valve; 240L (single or double bin) or standard 660L/1100L bins with bin lifter |
