| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 8450 × 2500 × 3200 mm | Transport Package | Bare painting and waxing treatment |
| Transportation | Ro-Ro / Bulk ship / Container vessel | Production Capacity | 100 units/month |
| Tare Weight | Approx. 14010 kg | Origin | Hubei, China |
| Delivery Time | Within 30 days | | |
| ②Chassis Specification |
| Chassis Brand | Dongfeng | Model | DFL1140B2-KG2E-952-012J |
| Drive Wheel | 4×2 | Wheelbase | 4500 mm |
| Driving Position | LHD or RHD | Cabin Seats | 3 |
| Cabin Color | According to customer requirements | Engine Model | Cummins B210 33 |
| Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification | Engine Rated Power | 154 kW |
| Engine Horsepower | 210 HP | Engine Max Torque | 700 N·m @ 1200–1800 rpm |
| Engine Number Of Cylinders | 6 | Engine Displacement | 5.9 L |
| Transmission Model | 8JS85TE-C | Pto | yes |
| Forward Gears | 8 | Reverse Gears | 2 |
| Transmission Type | Manual | Synchronized | Yes |
| Transmission Gear Ratios | Forward: 9.65, 6.46, 4.32, 3.19, 2.23, 1.50, 1.00, 0.74; Reverse: 9.81, 2.27 | Front Axle | Load capacity 6 tons |
| Rear Axle | Load capacity 10 tons | Axle Gear Ratio | Single reduction, ratio 5.29 |
| Tire Specification | 10.00R20 | Fuel Tank Capacity | 160 L |
| Fuel Tank Type | Steel fuel tank | Electric System | 24 V |
| Brake Type | Front and rear drum brakes | Braking Method | Air brake, air cut-off brake, ABS |
| ③Upper-Body Specification |
| Alarm Light Alarm | Tbd035191g, red, with 100W alarm | Water Treatment And Purification System | Customized |
| Water Quality Testing Box | Type 88 | Oil Fired Atmospheric Pressure Hot Water Boiler | CLHS0.12 |
| Booster Pump | Flow rate: 6 L/min | Stainless Steel Purified Water Tank | 2000 L (including water level display) |
| Water Pipeline System | Customized | Silent Generator | OM15CYD3 |
| Electric Control Panel | Customized | Interior Lighting | Customized |
| Portable Cable Tray Including Cable | Including power cord and portable cable tray | Traffic Sign Light | Including position light, side light and license plate light |
| Aviation Plug | Customized | Drain Hose | Φ25, 20 m length |
| Water Intake Hose | Φ50 polyurethane hose, 20 m length | Grounding Pile Including Grounding Wire | Customized |
| Mechanical Jack | 16 T | Dry Powder Fire Extinguisher | 1 piece |
