| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 8450 × 2500 × 3200 mm | Transport Package | Bare painting and waxing treatment |
| Transportation | Ro-Ro / Bulk ship / Container vessel | Production Capacity | 100 units/month |
| Tare Weight | Approx. 12010 kg | Origin | Hubei, China |
| Delivery Time | Within 30 days | | |
| ②Chassis Specification |
| Chassis Brand | Dongfeng | Model | DFL1140B2-KG2E-952-012J |
| Drive Wheel | 4×2 | Wheelbase | 4500 mm |
| Driving Position | LHD or RHD | Cabin Seats | 3 |
| Cabin Color | According to customer requirements | Engine Model | Cummins B210 33 |
| Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification | Engine Rated Power | 154 kW |
| Engine Horsepower | 210 HP | Engine Max Torque | 700 N·m @ 1200–1800 rpm |
| Engine Number Of Cylinders | 6 | Engine Displacement | 5.9 L |
| Transmission Model | 8JS85TE-C | Pto | yes |
| Forward Gears | 8 | Reverse Gears | 2 |
| Transmission Type | Manual | Synchronized | Yes |
| Transmission Gear Ratios | Forward: 9.65, 6.46, 4.32, 3.19, 2.23, 1.50, 1.00, 0.74; Reverse: 9.81, 2.27 | Front Axle | Load capacity 6 tons |
| Rear Axle | Load capacity 10 tons | Axle Gear Ratio | Single reduction, ratio 5.29 |
| Tire Specification | 10.00R20 | Fuel Tank Capacity | 160 L |
| Fuel Tank Type | Steel fuel tank | Electric System | 24 V |
| Brake Type | Front and rear drum brakes | Braking Method | Air brake, air cut-off brake, ABS |
| ③Upper-Body Specification |
| Box Body | Outer layer of aluminum alloy plate, inner layer filled with foam | Side Door | Side door with observation window |
| Floor | Aluminum alloy pattern plate | Non Slip Mat | Special toilet anti-slip water isolating pad, 2 sets |
| Window | 7 sliding windows on the side of the car, with curtains and screens | Window Curtains | Each window is equipped with a curtain |
| Roof Rear Ladder And Roof Rail | Stainless steel material | Skylight Ventilator | 24V, with escape device, 2 sets |
| Emergency Light | One in the front and one in the rear of the car, 2 sets | Top Light | Ceiling lamp, 3 sets |
| Battery | 200 Ah, 2 sets | Inverter | 2 kW |
| Oil Heater | Heating power 5 kW (7 kW required in alpine areas) | Boarding Ladder With Folding Railing | Anti-skid, anti-collision; one for rear door and one for equipment area |
| Air Conditioner | 1.5 hp wall-mounted air conditioner (changing area) | Electrical Control Box | Controls vehicle circuit |
| Battery Charger | Xiamen Tuobao | Power Protector | Power leakage overload overvoltage protection device |
| Cable Reel | 50 m (with cable reel) | Special Water Pump | 220 V |
| Packaged Squatting Pan | Adopts special packing type squatting pan for vehicles and ships, suitable for places without water and electricity | Combined Hand Washing Cabinet | Including wash basin, dressing mirror, trash can, etc |
| Clean Water Tank | 304 stainless steel | Water And Electricity Control System | Button embedded control panel |
| Reverse Navigation Monitoring System | Including camera, controller and 7-inch display screen | Dry Powder Fire Extinguisher | 1 piece |
| Smoke Detector | One in equipment area and one in changing area respectively | Lightning Arrester | Manual inverted lightning rod on roof |
