| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 8450 × 2500 × 3200 mm | Transport Package | Bare painting and waxing treatment |
| Transportation | Ro-Ro / Bulk ship / Container vessel | Production Capacity | 100 units/month |
| Tare Weight | Approx. 12010 kg | Origin | Hubei, China |
| Delivery Time | Within 30 days | | |
| ②Chassis Specification |
| Chassis Brand | Dongfeng | Model | DFL1140B2-KG2E-952-012J |
| Drive Wheel | 4×2 | Wheelbase | 4500 mm |
| Driving Position | LHD or RHD | Cabin Seats | 3 |
| Cabin Color | According to customer requirements | Engine Model | Cummins B210 33 |
| Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification | Engine Rated Power | 154 kW |
| Engine Horsepower | 210 HP | Engine Max Torque | 700 N·m @ 1200–1800 rpm |
| Engine Number Of Cylinders | 6 | Engine Displacement | 5.9 L |
| Transmission Model | 8JS85TE-C | Pto | yes |
| Forward Gears | 8 | Reverse Gears | 2 |
| Transmission Type | Manual | Synchronized | Yes |
| Transmission Gear Ratios | Forward: 9.65, 6.46, 4.32, 3.19, 2.23, 1.50, 1.00, 0.74; Reverse: 9.81, 2.27 | Front Axle | Load capacity 6 tons |
| Rear Axle | Load capacity 10 tons | Axle Gear Ratio | Single reduction, ratio 5.29 |
| Tire Specification | 10.00R20 | Fuel Tank Capacity | 160 L |
| Fuel Tank Type | Steel fuel tank | Electric System | 24 V |
| Brake Type | Front and rear drum brakes | Braking Method | Air brake, air cut-off brake, ABS |
| ③Upper-Body Specification |
| Body Material | Outer FRP, inner stainless steel | Electric Gas Dual Purpose Rice Cooker Specifications | Single door, 10 layers |
| Steaming Plate Material | Stainless Steel | Steamed Rice Plate Size | Length 0.6×Width 0.4 m |
| Mobile Field Cooking Truck Steaming Cabinet Size | L×W×H:0.68×0.54×1.32m | Number Of Available Personnel | for 300 people at the same time |
| Steaming Time | 35 min | Double Eye Cooktop Specification | Double Cooktop |
| Double Eye Cooktop Material | Stainless Steel | Double Eye Cooktop Size | Length 1.8/1.5×0.8×0.82 m |
| Double Eye Cooktop Fuel | Methanol/Diesel/Natural gas | Refrigerator Freezer Material | Stainless Steel |
| Refrigerator Freezer Size | L×W×H:1.5×0.6×0.8m | Sales Window Specifications | Up and Down, Up: Sun Visor |
| Operation Console Material | Brushed/Patterned Stainless Steel | Operation Console Size | Length 4.18×Width 0.64m |
| Sink Material | Stainless Steel | Sink Size | Length 0.42×Width 0.37m |
| Lighting Circuit | 15m external power cord | Dish Rack Specification | 2 layers |
| Dish Rack Material | Stainless Steel | Dish Rack Size | Length 4.18×Width 0.64m |
| Wall Cabinet Material | Stainless Steel | Wall Cabinet Size | 1500×400×300mm |
| Range Hood Material | Stainless Steel | Range Hood Device | Wall fan, Overhead Exhaust |
| Clean Water Tank Specifications | Stainless Steel, With Booster Pump | Clean Water Tank Volume | 290L, 0.5 square |
| Clean Water Tank Position | Front section of the compartment | Sewage Tank Specifications | stainless steel, with stainless steel ball valve |
| Sewage Tank Volume | 0.3 square | Sewage Tank Position | Car seat skirt |
| Fuel Tank Material | Stainless Steel | Fuel Tank Volume | 120L |
| Fuel Tank Position | Car skirt | Ventilation Window Size | 0.39×0.48m |
| Ventilation Window Quantity | 3 | Ladder Guardrail Material | Stainless Steel |
