| Item | Parameter | Item | Parameter |
| ①Basic Info. | |||
| Overall Dimensions (L×W×H) | 8450 × 2500 × 3200 mm | Load Capacity | 10-15 tons |
| Transport Package | Bare painting and waxing treatment | Transportation | Ro-Ro / Bulk ship / Container vessel |
| Production Capacity | 100 units/month | Tare Weight | Approx. 7310 kg |
| Origin | Hubei, China | Delivery Time | Within 30 days |
| ②Chassis Specification | |||
| Chassis Brand | Dongfeng | Model | DFH1180EX9 |
| Drive Wheel | 4×2 | Wheelbase | 4500 mm |
| Driving Position | LHD or RHD | Cabin Seats | 3 |
| Cabin Color | According to customer requirements | Engine Model | ISD300 50 |
| Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification | Engine Rated Power | 221 kW |
| Engine Horsepower | 300 HP | Engine Max Torque | 1100N.m |
| Engine Number Of Cylinders | 6 | Engine Displacement | 6.7L |
| Transmission Model | 9JS119TB | Pto | yes |
| Forward Gears | 9 | Reverse Gears | 2 |
| Transmission Type | Manual | Synchronized | Yes |
| Transmission Gear Ratios | 11.02 | Front Axle | Load capacity 6.5 tons |
| Rear Axle | Load capacity 12.5 tons | Tire Specification | 295/80R22.5 |
| Fuel Tank Capacity | 400 L | Fuel Tank Type | Aluminum alloy fuel tank |
| Electric System | 24 V | Brake Type | Front and rear drum brakes |
| Braking Method | Air brake, air cut-off brake, ABS | Other Configurations | Includes Clutch Booster, Connector/Plug for COM Port Installation, Automatic Slack Adjuster, Exhaust Brake, Dryer and Rear Underrun Protector with ABS/ESC, Front Shock Absorber, Front Anti-roll Bar, Roof Fairing, Front Underrun Protector, Window Regulator, Central Locking, Turn Signal Lamp, Front Fog Lamp, Parking Lamp, Daytime Running Lamp, Heated Windshield Glass, Front/Rearview Mirror, Interior Light Activated When Door Opens, Adjustable Seat, Cab Air Suspension Seat, Driver Seat Belt Reminder Indicator, Reverse Camera, Cruise Control, Bluetooth Connection, Multifunction Steering Wheel, Standard Instrument Cluster, Pneumatic Horn, Electric Horn, Air Conditioner. |
| ③Upper-Body Specification | |||
| Tank Volume | Q345 carbon | Tank Materials | Plastic-lined steel (carbon steel shell with inner PE layer) |
| Tank Thickness | Bottom: 4 mm, Side: 3 mm | Tank Shape | Curved box |
| Tank Design | Integralleak-proofdesign | Sewage Tank Capacity | 3000 L, 5000 L |
| Filler Capacity | 1.2(cbm) | Fill Time | 8–10 s |
| Discharge Time | 30–40 s | Mode | Electronically controlled with manual backup |
| Hydraulic Pressure | 16 MPa | Dry Wet Separation Function | Yes |
| Tumbler Mechanism | Chain lifter on right side for 120L and 240L garbage bins | ||
