| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 5990 × 2050 × 2550 mm | Load Capacity | 5 tons |
| Transport Package | Bare painting and waxing treatment | Transportation | Ro-Ro / Bulk ship / Container vessel |
| Production Capacity | 100 units/month | Tare Weight | Approx. 3670 kg |
| Origin | Hubei, China | Delivery Time | Within 30 days |
| ②Chassis Specification |
| Chassis Brand | Dongfeng | Model | CE90-301-201J |
| Drive Wheel | 4×2 | Wheelbase | 3300 mm |
| Cabin Model | B19S Wide Body Cab | Driving Position | LHD or RHD |
| Cabin Seats | 3 | Cabin Color | According to customer requirements |
| Engine Model | YC4FA120-33 | Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification |
| Engine Rated Power | 88 kW | Engine Horsepower | 120 HP |
| Engine Max Torque | 345 N·m | Engine Number Of Cylinders | 4 |
| Engine Displacement | 2.98 L | Transmission Model | WLY5TS40 |
| Pto | yes | Forward Gears | 5 |
| Reverse Gears | 1 | Transmission Type | Manual |
| Transmission Gear Ratios | 1st Gear Ratio: 5.06 | Front Axle | Load capacity 1.8 tons |
| Rear Axle | Load capacity 3.5 tons | Tire Specification | 7.00R16LT 14PR |
| Fuel Tank Capacity | 120 L | Fuel Tank Type | Aluminum alloy tank |
| Electric System | 24 V | Brake Type | Front and rear drum brakes |
| Braking Method | Air brake, air cut-off brake | Other Configurations | As per standard configuration |
| ③Upper-Body Specification |
| Tank Thickness | Carbon steel shell 5 mm, ends 6 mm, inner PE layer 18 mm | Tank Shape | Oval or square (optional) |
| Garbage Compactor Truck Tank Materials | Q235 carbon steel (special steel) | Tank Design | Integral leak-proof design |
| Unloading Time | ≤45 s | Control Mode | Electric/Manual/Remote (three modes standard) |
| Engine Power Control | Fully automatic | Max Hydraulic System Pressure | 20 MPa |
| Manufacturing Process | Whole plate forming | Control System | PLC |
| Compaction Ratio | 1:3 to 1:4 | Control Panel Language | English or as requested |
| Garbage Compactor Truck Hopper Effective Volume | ≥0.8 m³ | Standard Accessories | Dustbin lifter, ladder, warning lights, emergency stop button, handrail, fire extinguisher, basic tool kit, English manual |
| Loading Method | Rear loading, optional bin lifting system | Optional | Rear view camera and backup alarm; Italian multi-way valve; 240L (single or double bin) or standard 660L/1100L bins with bin lifter |
