| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 9960 × 2550 × 3450 mm | Load Capacity | 16 / 20 tons |
| Transport Package | Bare painting and waxing treatment | Transportation | Ro-Ro / Bulk ship / Container vessel |
| Production Capacity | 100 units/month | Tare Weight | Approx. 11600 kg |
| Origin | Hubei, China | Delivery Time | Within 30 days |
| ②Chassis Specification |
| Chassis Brand | Dongfeng | Drive Wheel | 6×4 |
| Wheelbase | 5850+1350 mm | Cabin Model | T5 Cabin with Sleeper |
| Driving Position | LHD or RHD | Cabin Seats | 3 |
| Cabin Color | According to customer requirements | Engine Model | YC6A260-33 |
| Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification | Engine Rated Power | 191 kW |
| Engine Horsepower | 260 HP | Engine Max Torque | 1000 N·m @ 1300–1600 rpm |
| Engine Number Of Cylinders | 6 | Engine Displacement | 7.255 L |
| Transmission Model | 9JS119TA | Pto | yes |
| Forward Gears | 9 | Reverse Gears | 1 |
| Transmission Type | Manual | Synchronized | Yes |
| Transmission Gear Ratios | Forward: 9.65, 6.46, 4.32, 3.19, 2.23, 1.50, 1.00, 0.74; Reverse: 9.81, 2.27 | Front Axle | Load capacity 6.5 tons |
| Rear Axle | Load capacity 11.5 tons × 2 | Axle Gear Ratio | Single reduction, ratio 5.571 |
| Tire Specification | 11.00R20 18PR | Front Suspension | 10-leaf spring |
| Rear Suspension | 13-leaf spring | Fuel Tank Capacity | 350 L |
| Fuel Tank Type | Aluminum alloy tank | Electric System | 24 V |
| Brake Type | Front and rear drum brakes | Braking Method | Air brake, air cut-off brake, ABS |
| Other Configurations | The cab features air suspension driver seat, multifunction steering wheel, mechanical instrument cluster, remote central locking with multi-function keyless entry, electric windows, sun visor, and two-point cab suspension, balancing comfort and operational convenience. | | |
| ③Upper-Body Specification |
| Tank Volume | 5000–20000 L | Tank Material | High strength and wear-resistant steel |
| Types Of Dished Ends | Rotary press forming | Maximum Tipping Angle | 40° |
| Maximum Internal Working Vacuum | -0.078 MPa | Vacuum Pump | Roots Type RSR20 |
| Drive Mode | Independent PTO System | Suction Method | Vacuum Suction |
| Suction Rate | 30–80 t/h | Suction Line Inner Diameter | 150 mm |
| Dust Filtration Method | Gravity inertial dust collection + fabric filtration | Filter Bag Cleaning Method | Blowback |
| Exhaust Dust Concentration | 20 mg/m³ | Discharge Method | Positive pressure discharge or rear hatch lift-dumping |
| Air Source Equipment | Air compressor or external ground air source | Air Compressor | Wuhu Fuda, 10 m³/min |
| Maximum Working Pressure | 30 MPa | Rear Cover Opening Method | Hydraulic |
| Maximum Rear Cover Opening Angle | 60° | Rear Cover Locking Method | Hydraulic locking with locking rod |
| Residual Material Rate Inside The Tank | ≤2‰ | Lifting Cylinder | Hubei Jiaheng |
| Shaft End Diameter | Φ60 mm | Rated Pressure | 20 MPa |
| Hydraulic Oil Tank Volume | ≈80 L | Suction Valve | Valve DN150, Interface DN150 |
| Discharge Valve | Located on rear end cover, DN150, aluminum alloy | Other Valves | DN50–DN200 |
