| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 5995 × 2000 × 2460 mm | Load Capacity | 5 tons |
| Transport Package | Bare painting and waxing treatment | Transportation | Ro-Ro / Bulk ship / Container vessel |
| Production Capacity | 100 units/month | Tare Weight | Approx. 3825 kg |
| Origin | Hubei, China | Delivery Time | Within 30 days |
| ②Chassis Specification |
| Chassis Brand | Dongfeng | Drive Wheel | 4×2 |
| Wheelbase | 3300 mm | Driving Position | LHD or RHD |
| Cabin Seats | 3 | Cabin Color | According to customer requirements |
| Engine Model | YN38CRD1 | Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification |
| Engine Rated Power | 95 kW | Engine Horsepower | 129 HP |
| Engine Max Torque | 365 N·m / 1600-2400 r/min | Engine Number Of Cylinders | 4 |
| Engine Displacement | 3.76 L | Transmission Model | WLY6TS55 |
| Pto | yes | Forward Gears | 6 |
| Reverse Gears | 1 | Transmission Type | Manual |
| Front Axle | 2.4T | Rear Axle | 4.2T |
| Tire Specification | 7.00R16 14PR | Fuel Tank Capacity | 120 L |
| Fuel Tank Type | Aluminum alloy tank | Electric System | 24 V |
| Brake Type | Front and rear drum brakes | Braking Method | Air brake, air cut-off brake, ABS |
| ③Upper-Body Specification |
| Tank Volume | 5000 L | Water Sprinkler Truck Tank Materials | Carbon steel or aluminum alloy or stainless steel |
| Water Sprinkler Truck Dished Head Thickness | 5 mm | Tank Shape | Oval or square (optional) |
| Water Pump (Self-priming) | QZ60/90, Yifeng or other Chinese brands, Flow 60 m³/h, Head 90 m | Water Sprinkler Truck Other Equipment | Front flush, rear spray, side sprinklers, rear working platform with water cannon, one fire hydrant interface |
| Manhole | DN450 (18 inches) | Liquid Line | DN50 (2 inches) |
| Filling Hose | 10 m | Top Safety Rail | 1 set |
