| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 78600 × 2500 × 3200 mm | Load Capacity | 11-14 tons |
| Transport Package | Bare painting and waxing treatment | Transportation | Ro-Ro / Bulk ship / Container vessel |
| Production Capacity | 100 units/month | Tare Weight | Approx. 9000/10600 kg |
| Origin | Hubei, China | Delivery Time | Within 30 days |
| ②Chassis Specification |
| Chassis Brand | Dongfeng | Model | EQ1188GSZ6DJ |
| Drive Wheel | 4×2 | Wheelbase | 4500 mm |
| Driving Position | LHD or RHD | Cabin Seats | 3 |
| Cabin Color | According to customer requirements | Engine Model | YCS06220-60 |
| Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification | Engine Rated Power | 162 kW |
| Engine Horsepower | 220 HP | Engine Max Torque | 800N.m/1200-1700rpm |
| Engine Number Of Cylinders | 4 | Engine Displacement | 6.234 L |
| Transmission Model | 8JS85TE-C | Pto | yes |
| Forward Gears | 8 | Reverse Gears | 1 |
| Transmission Type | Manual | Synchronized | Yes |
| Transmission Gear Ratios | 10.36 | Front Axle | Load capacity 6.5 T |
| Rear Axle | 16 T × 2 | Tire Specification | 11.00R20 18PR |
| Fuel Tank Capacity | 250 L | Fuel Tank Type | Steel fuel tank |
| Electric System | 24 V | Brake Type | Front and rear drum brakes |
| Braking Method | Air brake, air cut-off brake, ABS | | |
| ③Upper-Body Specification |
| Tank Volume | 13400 L | Fuel Tank Truck Tank Material | Carbon steel or aluminum alloy or stainless steel |
| Fuel Tank Truck Dished Head Thickness | 6 mm | Fuel Tank Truck Number Of Compartments | 2 to 6 compartments, or customized as required |
| Emergency Bottom Valve | Aluminum alloy / Stainless steel | Discharging Valve | 3", 4" or 6" diameter |
| Oil Pump | YHCB/80/60, 50 m³/h | Manhole | DN450 (18 inches) |
| Liquid Line | DN50 (2 inches) | Filling Hose | 15 m |
| Top Safety Rail | 1 set | Oil Gas Recovery System | Optional |
| Fuel Dispenser & Hose Reel | Optional | | |
