| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 6700 × 2359 × 2800 mm | Load Capacity | 7 / 10 tons |
| Transport Package | Bare painting and waxing treatment | Transportation | Ro-Ro / Bulk ship / Container vessel |
| Production Capacity | 100 units/month | Tare Weight | Approx. 4800 kg |
| Origin | Hubei, China | Delivery Time | Within 30 days |
| ②Chassis Specification |
| Chassis Brand | Sinotruk | Model | ZZ1107D3815D1 |
| Drive Wheel | 4×2 | Wheelbase | 3800 mm |
| Cabin Model | 2080 | Driving Position | LHD or RHD |
| Cabin Seats | 3 | Cabin Color | According to customer requirements |
| Engine Model | YN38CRD1 | Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification |
| Engine Rated Power | 95 kW | Engine Horsepower | 129 HP |
| Engine Max Torque | 365 N·m / 1600-2400 r/min | Engine Number Of Cylinders | 4 |
| Engine Displacement | 3.76 L | Transmission Model | WLY6TS55 |
| Pto | yes | Forward Gears | 6 |
| Reverse Gears | 1 | Transmission Type | Manual |
| Synchronized | Yes | Front Axle | 2.7T |
| Rear Axle | 7.2T | Axle Gear Ratio | 5.286 |
| Tire Specification | 8.25R16 | Fuel Tank Capacity | 120 L |
| Fuel Tank Type | Aluminum alloy tank | Electric System | 24 V |
| Brake Type | Front and rear drum brakes | Braking Method | Air brake, air cut-off brake, ABS |
| ③Upper-Body Specification |
| Water Supply Truck Tank Volume | 7000 L | Water Supply Truck Tank Materials | SUS304-2B food-grade stainless steel |
| Water Supply Truck Material Thickness | 3.5 mm | Water Supply Truck Number Of Compartments | 2 to 6 compartments or customized as needed |
| Water Supply Truck Tank Welding | Tungsten Inert Gas Welding Process | Water Supply Truck Valve Material | SUS304 butterfly valve |
| Water Supply Truck Pipe Material | SUS304 stainless steel | Water Supply Truck Inside The Tank | Pickling and Passivation Treatment |
| Water Supply Truck Pump Tank | Stainless steel pump tank | Water Supply Truck Strainer | Pump Inlet Stainless Steel Filter |
| Water Supply Truck Valve Diameter | DN63 Clamp-Type Butterfly Valve | Water Supply Truck Manhole | 1 DN500 stainless steel |
| Water Supply Truck Top Safety Rail | 1 set | | |
