| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 12100 × 2500 × 3800 mm | Load Capacity | 35 / 50 tons |
| Transport Package | Bare painting and waxing treatment | Transportation | Ro-Ro / Bulk ship / Container vessel |
| Production Capacity | 100 units/month | Tare Weight | Approx. 9900 kg |
| Origin | Hubei, China | Delivery Time | Within 30 days |
| ②Chassis Specification |
| Main Beams | Steel Q345B or aluminum alloy | Kingpin | 2" or 3.5", brand optional |
| Braking System | RE6 relay valve, spring brake chamber, 2 pieces of 45 L air tanks | Tire | 12.00R20 / 315/80R22.5, brand optional |
| Spare Tire Carrier | 2 pieces | ABS System | Optional |
| Tool Box | 1 piece standard | Fire Extinguisher | 2 pieces |
| Axle | 13T/16T, FUWA/BPW brand (manual operation not applicable) | Suspension | Mechanical suspension / Air suspension |
| Leaf Spring | 90 mm (W) × 13 mm (T) × 10 layers or 100 mm × 12 mm × 12 layers | Landing Gear | JOST (D200T) or Chinese brand 28T (two-speed) |
| Rim | 9.00-22.5 / 8.0-20 / 8.5-20 | Safety Guard | Standard |
| Lights | LED, 24V | Painting | Complete chassis sandblasting to remove rust, 1 coat of anti-corrosion primer, 2 coats of top paint |
| ③Upper-Body Specification |
| Tank Volume | 46500 L | Fuel Tank Truck Tank Material | Carbon steel |
| Fuel Tank Truck Dished Head Thickness | 6 mm | Fuel Tank Truck Number Of Compartments | 2 to 6 compartments, or customized as required |
| Emergency Bottom Valve | Aluminum alloy / Stainless steel | Discharging Valve | 3", 4" or 6" diameter |
| Oil Pump | YHCB/80/60, 50 m³/h | Manhole | DN450 (18 inches) |
| Liquid Line | DN50 (2 inches) | Filling Hose | 18 m |
| Top Safety Rail | 1 set | Oil Gas Recovery System | Optional |
