| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 12100 × 2500 × 3800 mm | Load Capacity | 35 / 50 tons |
| Transport Package | Bare painting and waxing treatment | Transportation | Ro-Ro / Bulk ship / Container vessel |
| Production Capacity | 100 units/month | Tare Weight | Approx. 9900 kg |
| Origin | Hubei, China | Delivery Time | Within 30 days |
| ②Chassis Specification |
| Main Beams | Steel Q345B or aluminum alloy | Kingpin | 2" or 3.5", brand optional |
| Braking System | RE6 relay valve, spring brake chamber, 2 pieces of 45 L air tanks | Tire | 12.00R20 / 315/80R22.5, brand optional |
| Spare Tire Carrier | 2 pieces | ABS System | Optional |
| Tool Box | 1 piece standard | Fire Extinguisher | 2 pieces |
| Axle | 13T/16T, FUWA/BPW brand (manual operation not applicable) | Suspension | Mechanical suspension / Air suspension |
| Leaf Spring | 90 mm (W) × 13 mm (T) × 10 layers or 100 mm × 12 mm × 12 layers | Landing Gear | JOST (D200T) or Chinese brand 28T (two-speed) |
| Rim | 9.00-22.5 / 8.0-20 / 8.5-20 | Safety Guard | Standard |
| Lights | LED, 24V | Painting | Complete chassis sandblasting to remove rust, 1 coat of anti-corrosion primer, 2 coats of top paint |
| ③Upper-Body Specification |
| Powder Material Transport Vehicle Tank Volume | Dry mix 28 cubic meters, bulk cement 30 cubic meters | Powder Material Transport Vehicle Tank Material | High strength and wear-resistant steel |
| Powder Material Transport Vehicle Tank Head Thickness | 5 mm | Powder Material Transport Vehicle Conveying Height | ≥15 m |
| Powder Material Transport Vehicle Conveying Distance | ≥30 m | Powder Material Transport Vehicle Air Compressor | 10 m³ large air compressor |
| Powder Material Transport Vehicle Safety Valve | Full lift type | Powder Material Transport Vehicle One Way Check Valve | DN65 |
| Powder Material Transport Vehicle Intake Valve | DN50 | Powder Material Transport Vehicle Climbing Stairs | Standard configuration |
| Powder Material Transport Vehicle Quantity Of Silos | 3 | Powder Material Transport Vehicle External Gas Source | Aluminum alloy valve |
| Powder Material Transport Vehicle Pressure Gauge | Shock resistant and wear-resistant | Powder Material Transport Vehicle Discharge Valve | DN100 |
| Powder Material Transport Vehicle Discharge Port | 1 unit | Powder Material Transport Vehicle Discharge Pipe | Built-in steel wire rubber tube, 7 m long |
