| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 11200 × 2500 × 3800 mm | Load Capacity | 35 / 50 tons |
| Transport Package | Bare painting and waxing treatment | Transportation | Ro-Ro / Bulk ship / Container vessel |
| Production Capacity | 100 units/month | Tare Weight | Approx. 9800 kg |
| Origin | Hubei, China | Delivery Time | Within 30 days |
| ②Chassis Specification |
| Main Beams | Steel Q345B or aluminum alloy | Kingpin | 2" or 3.5", brand optional |
| Braking System | RE6 relay valve, spring brake chamber, 2 pieces of 45 L air tanks | Tire | 12.00R20 / 315/80R22.5, brand optional |
| Spare Tire Carrier | 2 pieces | ABS System | Optional |
| Tool Box | 1 piece standard | Fire Extinguisher | 2 pieces |
| Axle | 13T/16T, FUWA/BPW brand (manual operation not applicable) | Suspension | Mechanical suspension / Air suspension |
| Leaf Spring | 90 mm (W) × 13 mm (T) × 10 layers or 100 mm × 12 mm × 12 layers | Landing Gear | JOST (D200T) or Chinese brand 28T (two-speed) |
| Rim | 9.00-22.5 / 8.0-20 / 8.5-20 | Safety Guard | Standard |
| Lights | LED, 24V | Painting | Complete chassis sandblasting to remove rust, 1 coat of anti-corrosion primer, 2 coats of top paint |
| ③Upper-Body Specification |
| Tank Volume | 25000 L | Loading Capacity | 35/50 T |
| Tank Materials | Plastic-lined steel (carbon steel shell with inner PE layer) | Tank Thickness | Carbon steel shell 5 mm, ends 6 mm, inner PE layer 18 mm |
| Corrosive Materials Tank Truck Manhole Cover | 2 units, plastic-lined steel manhole and cover | Air Valve | 2 units, DN50 PE-made air valve |
| Inlet Hole | 2 units with manhole loading inlet | Discharge Outlet | 2 units, DN80 PE ball valve on each rear side of tanker |
| Master Control Valve | PTFE butterfly valve | Discharge Platform Cabinet | To manufacturer's standard, carbon steel cabinet with lock |
| Corrosive Materials Tank Truck Discharge Hose | 2 units, 6 m approved delivery hose | Corrosive Materials Tank Truck Man Walkway | Anti-skid iron walkway on top of tanker |
| Fire Extinguisher Cage | 2 pcs x 8 kg fire extinguisher, mounted at sides of vehicle | Tank Coating | Sandblasted, 1 coat anti-rust primer, 1 coat base, 1 coat finishing in dark grey. Color and materials per manufacturer's standard and availability. |
