| Item | Parameter | Item | Parameter |
| ①Basic Info. | |||
| Overall Dimensions (L×W×H) | 8450 × 2500 × 3100 mm | Load Capacity | 13 / 15 tons |
| Transport Package | Bare painting and waxing treatment | Transportation | Ro-Ro / Bulk ship / Container vessel |
| Production Capacity | 100 units/month | Tare Weight | Approx. 8000 / 12800 kg |
| Origin | Hubei, China | Delivery Time | Within 50 days |
| ②Chassis Specification | |||
| Chassis Brand | Dongfeng | Model | DFH1180EX9 |
| Drive Wheel | 4×2 | Wheelbase | 4700 mm |
| Driving Position | LHD or RHD | Cabin Seats | 3 |
| Cabin Color | According to customer requirements | Engine Model | B6.2NS6B260 |
| Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification | Engine Rated Power | 191 kW |
| Engine Horsepower | 260 HP | Engine Max Torque | 1020 N·m @ 1300-1700 rpm |
| Engine Number Of Cylinders | 6 | Engine Displacement | 6.2 L |
| Transmission Model | 8JS85TE-C | Pto | yes |
| Forward Gears | 8 | Reverse Gears | 2 |
| Transmission Type | Manual | Synchronized | Yes |
| Transmission Gear Ratios | 10.36 | Front Axle | Load capacity 4.5 tons |
| Rear Axle | Load capacity 9 tons | Tire Specification | 275/70R22.5 18PR |
| Fuel Tank Capacity | 160 L | Fuel Tank Type | Aluminum alloy tank |
| Electric System | 24 V | Brake Type | Front and rear drum brakes |
| Braking Method | Air brake, air cut-off brake, ABS | ||
| ③Upper-Body Specification | |||
| Tank Volume | 13400 L | Aircraft Refueling Type | gravity |
| Aircraft Refueling Vehicle Tank Material | High-quality aluminum alloy | Aircraft Refueling Vehicle Dished Head Thickness | 6 mm |
| Aircraft Refueling Vehicle Refueling Pump | Self-priming centrifugal pump, hose reel refueling flow 100–150 L/min, pipeline fuel extraction flow 700 L/min, working pressure 0.25 MPa | Flowmeter | Flow range 250–2500 L/min, accuracy not lower than Class 0.2, working pressure 1.0 MPa |
| Filter Separator | Rated flow 400 L/min, rated working pressure 1.0 MPa, maximum allowable differential pressure 0.15 MPa, complies with API 1581 3rd Edition | Gravity Hose Reel | Refueling hose nominal diameter DN38 (38 mm), hose length 15 m |
| Tank Level Gauge | Type: stainless steel float (inside tank); mounting position: left side of tank; dial: 4-inch aluminum alloy dial; function: clearly displays current liquid volume in tank | Operating System | Centralized control in independent control cabin |
| Instrumentation | Pump inlet vacuum gauge, pump outlet pressure gauge, pump tachometer, filter differential pressure gauge | Valve Switch Operations | Main power switch, lighting switch, emergency stop switch, pump speed control knob, refueling valve, circulation/filtration valve, sampling valve, emergency valve control switch |
| Functions | 1. Hose reel refueling – transfers fuel from vehicle tank to aircraft fuel tank or other receiving equipment via gravity refueling nozzle on hose reel in control cabin, after filtration and metering. 2. Fuel pumping and filtration – circulates and filters fuel from vehicle tank or external pipeline, returning it to vehicle tank or other receiving equipment through pump outlet connection. 3. Tank loading – loads fuel into tank from external pipeline via bottom loading connection, or by using fuel pump to extract fuel. | ||
