| Item | Parameter | Item | Parameter |
| ①Basic Info. |
| Overall Dimensions (L×W×H) | 8490 × 2550 × 3400 mm | Load Capacity | 8 / 11 tons |
| Transport Package | Bare painting and waxing treatment | Transportation | Ro-Ro / Bulk ship / Container vessel |
| Production Capacity | 100 units/month | Tare Weight | Approx. 8000 / 12800 kg |
| Origin | Hubei, China | Delivery Time | Within 30 days |
| ②Chassis Specification |
| Chassis Brand | Dongfeng | Model | DFH1180EX9 |
| Drive Wheel | 4×2 | Wheelbase | 4500 mm |
| Cabin Model | D9 | Driving Position | LHD or RHD |
| Cabin Seats | 3 | Cabin Color | According to customer requirements |
| Engine Model | ISD300 50 | Emission Standard | Euro II / Euro III / Euro IV / Euro V / Euro VI / Customized to specification |
| Engine Rated Power | 221 kW | Engine Horsepower | 300 HP |
| Engine Max Torque | 1100N.m | Engine Number Of Cylinders | 6 |
| Engine Displacement | 6.7 L | Transmission Model | 9JS119TB |
| Pto | yes | Forward Gears | 9 |
| Reverse Gears | 2 | Transmission Type | Manual |
| Synchronized | Yes | Transmission Gear Ratios | 11.02 |
| Front Axle | Load capacity 6.5 tons | Rear Axle | Load capacity 12.5 tons |
| Tire Specification | 295/80R22.5 | Fuel Tank Capacity | 400 L |
| Fuel Tank Type | Aluminum alloy tank | Electric System | 24 V |
| Brake Type | Front and rear drum brakes | Braking Method | Air brake, air cut-off brake, ABS |
| Other Configurations | Includes Clutch Booster, Connector/Plug for COM Port Installation, Automatic Slack Adjuster, Exhaust Brake, Dryer and Rear Underrun Protector with ABS/ESC, Front Shock Absorber, Front Anti-roll Bar, Roof Fairing, Front Underrun Protector, Window Regulator, Central Locking, Turn Signal Lamp, Front Fog Lamp, Parking Lamp, Daytime Running Lamp, Heated Windshield Glass, Front/Rearview Mirror, Interior Light Activated When Door Opens, Adjustable Seat, Cab Air Suspension Seat, Driver Seat Belt Reminder Indicator, Reverse Camera, Cruise Control, Bluetooth Connection, Multifunction Steering Wheel, Standard Instrument Cluster, Pneumatic Horn, Electric Horn, Air Conditioner. | | |
| ③Upper-Body Specification |
| Tank Volume | 10200 L | Loading Capacity | 8/15 T |
| Tank Materials | Plastic-lined steel (carbon steel shell with inner PE layer) | Tank Thickness | Carbon steel shell 5 mm, ends 6 mm, inner PE layer 18 mm |
| Corrosive Materials Tank Truck Manhole Cover | 2 units, plastic-lined steel manhole and cover | Air Valve | 2 units, DN50 PE-made air valve |
| Inlet Hole | 2 units with manhole loading inlet | Discharge Outlet | 2 units, DN80 PE ball valve on each rear side of tanker |
| Master Control Valve | PTFE butterfly valve | Discharge Platform Cabinet | To manufacturer's standard, carbon steel cabinet with lock |
| Corrosive Materials Tank Truck Discharge Hose | 2 units, 6 m approved delivery hose | Corrosive Materials Tank Truck Man Walkway | Anti-skid iron walkway on top of tanker |
| Fire Extinguisher Cage | 2 pcs x 8 kg fire extinguisher, mounted at sides of vehicle | Tank Coating | Sandblasted, 1 coat anti-rust primer, 1 coat base, 1 coat finishing in dark grey. Color and materials per manufacturer's standard and availability. |
